A rocket propulsion system with two TPs delivers the fuel, namely unsymmetrical dimethylhydrazine (UDMH), at a pump discharge pressure of 555 psia, a suction pressure of 25 psi, a flow of $10.2 \mathrm{lbm} / \mathrm{sec}$, at $3860 \mathrm{rpm}$, and a fuel temperature of $68^{\circ} \mathrm{F}$. Using UDMH properties from Table $7=1$ and Eig $7-1$ and its efficiency from $\underline{\text { Table } 10-2}$, determine the following: a. The fuel pump power for these nominal conditions. b. If the fuel flow is reduced to $70 \%$ of nominal, what will be the approximate power level, discharge pressure, and shaft speed? Assume that the oxidizer pump is also reduced by $70 \%$ and also the gas flow to the turbines, but that the gas temperature is unchanged. c. If the anticipated temperature variation of the propellants is between $40^{\circ} \mathrm{F}$ and $+120^{\circ} \mathrm{F}$, describe qualitatively how this variation will affect the power level, shaft speed, and the discharge pressure of the fuel pump.

A rocket propulsion system with two TPs delivers the fuel, namely unsymmetrical dimethylhydrazine (UDMH), at a pump discharge pressure of 555 psia, a suction pressure of 25 psi, a flow of $10.2 \mathrm{lbm} / \mathrm{sec}$, at $3860 \mathrm{rpm}$, and a fuel temperature of $68^{\circ} \mathrm{F}$. Using UDMH properties from Table $7=1$ and Eig $7-1$ and its efficiency from $\underline{\text { Table } 10-2}$, determine the following:
a. The fuel pump power for these nominal conditions.
b. If the fuel flow is reduced to $70 \%$ of nominal, what will be the approximate power level, discharge pressure, and shaft speed? Assume that the oxidizer pump is also reduced by $70 \%$ and also the gas flow to the turbines, but that the gas temperature is unchanged.
c. If the anticipated temperature variation of the propellants is between $40^{\circ} \mathrm{F}$ and $+120^{\circ} \mathrm{F}$, describe qualitatively how this variation will affect the power level, shaft speed, and the discharge pressure of the fuel pump.

Key Concepts

Affinity Laws for Centrifugal Pumps

The affinity laws provide relationships between the speed, flow rate, head, and power consumption in centrifugal pumps. They are used to predict how changes in the pump’s operating conditions, such as a reduction in flow or a change in shaft speed, affect performance parameters. These laws are fundamental when scaling the operation of a pump system, including changes due to throttle adjustments or variable operating conditions.

Pump Power Calculations

This concept involves determining the power required by a pump based on the pressure increase it must provide, the flow rate of the fluid, and the pump's efficiency. It requires understanding the energy balance for moving the fluid from a lower to a higher pressure level, and typically uses formulas that relate the pressure difference, volumetric flow rate, and mechanical work done to overcome fluid resistance and system losses.

Pump Efficiency

Pump efficiency is a measure of how effectively the pump converts input mechanical energy into useful hydraulic energy. This concept is critical in performance calculations because it directly affects the required power input. Efficiency can vary with operating conditions such as flow rate, temperature, and mechanical speed, and is often determined from empirical data and performance tables.

Thermal Effects on Fluid Properties

Temperature variations in the working fluid influence its density and viscosity, which in turn affect pump performance. As temperature increases or decreases, the fluid dynamics change, possibly altering the power requirements, discharge pressures, and pump speeds needed to maintain desired flow conditions. Understanding these effects is important for ensuring reliable pump operation across a range of anticipated operating temperatures.

Integrated Turbopump and Propulsion System Scaling

This concept involves recognizing that in an integrated propulsion system, changes in one component (like reducing fuel flow) typically require corresponding adjustments in related components such as turbine gas flows or oxidizer flows. The scaling of these interconnected parameters is crucial for maintaining overall system performance and ensuring that reductions or variations in one aspect of the system are accommodated by proportional changes in pump speed, pressure, and power consumption.
