A series $R L C$ circuit is driven by a signal generator. The resonant frequency of the network is known to be $1600 \mathrm{rad} / \mathrm{s}$ and at that frequency the impedance seen by the signal generator is $5 \Omega$. If $C=20 \mu \mathrm{F},$ find $L, Q,$ and the bandwidth.

Key Concepts

Bandwidth in Resonant Circuits

Bandwidth refers to the range of frequencies over which the circuit responds effectively, typically measured between the half-power (-3 dB) points of the response curve. In a resonant circuit, the bandwidth is inversely proportional to the quality factor, meaning that a circuit with high Q will have a narrow bandwidth. This concept is key in applications like filters, where controlling the frequency range is critical.

Resonance in RLC Circuits

Resonance in an RLC circuit occurs when the inductive reactance equals the capacitive reactance, causing them to cancel each other out. At this frequency, the circuit behaves as if it were purely resistive, and the voltage and current are in phase. This condition is essential in tuning applications, where a specific frequency is desired for maximum power transfer or selective filtering.

Impedance in AC Circuits

Impedance is the total opposition a circuit presents to alternating current, combining both resistance and reactance (from capacitors and inductors). In a series RLC circuit at resonance, the impedance is minimized and equals the resistance. Understanding impedance is crucial for analyzing how circuits respond to different frequencies and ensuring efficient energy transfer from the source.

Quality Factor (Q)

The quality factor, Q, measures the sharpness or selectivity of the resonance in the circuit. A high Q indicates a narrow bandwidth with sharp resonance peaks, meaning the circuit is sensitive to frequency variations around the resonant frequency. It is defined as the ratio of the resonant frequency to the bandwidth, and is also related to the energy stored versus energy dissipated in the circuit.
