A series R L C circuit with R=47 Ω, L=250 mH, and C=4.0 μF is connected across a sine-wave gener

step 1 Well, R is equal to 47 oom, and inductance L is equal to 0 .25 Fenry. And also we have capacitan

A series R L C circuit with R=47 Ω, L=250 mH, and C=4.0 μF...

A series $R L C$ circuit with $R=47 \Omega, L=250 \mathrm{mH},$ and $C=4.0 \mu \mathrm{F}$ is connected across a sine-wave generator whose peak output voltage is independent of frequency. Find the frequency range over which the peak current will exceed half its value at resonance.

Key Concepts

Series RLC Circuit

A Series RLC Circuit consists of a resistor, an inductor, and a capacitor connected in series. This circuit is widely used to study the interaction between resistance, inductance, and capacitance in AC circuits, showing how these elements combine to affect the current and voltage magnitude and phase across various frequencies.

Resonance in Series RLC Circuits

Resonance occurs in a series RLC circuit when the inductive and capacitive reactances cancel each other out, resulting in a purely resistive impedance at a specific frequency known as the resonance frequency. At resonance, the circuit experiences a peak current or maximum voltage transfer, making it a critical concept for frequency-selective applications.

Impedance in AC Circuits

Impedance is the total opposition a circuit presents to alternating current and is a combination of resistance and reactance. In a series RLC circuit, the impedance changes with frequency due to the frequency-dependent reactances of the inductor and capacitor, directly affecting the current amplitude and phase in the circuit.

Bandwidth and Half-Power Points

The bandwidth of a circuit refers to the range of frequencies over which the circuit’s performance (such as current or voltage) remains above a certain level—in this case, more than half of its maximum value at resonance. This is often associated with the half-power or -3 dB points, which are key parameters in understanding the frequency response of the circuit.

Quality Factor

The Quality Factor, or Q factor, is a dimensionless parameter that describes how underdamped an RLC circuit is and quantifies the sharpness of its resonance peak. A higher Q factor indicates a narrow bandwidth with a sharp resonance, while a lower Q factor corresponds to a broader bandwidth, influencing the selectivity and response of the circuit to changes in frequency.
