Question

A shunt motor develops $80 \mathrm{~N} \cdot \mathrm{m}$ of torque when the flux density in the air gap is $1.0 \mathrm{~Wb} / \mathrm{m}^{2}$ and the armature current is $15 \mathrm{~A}$. What is the torque when the flux density is $1.3 \mathrm{~Wb} / \mathrm{m}^{2}$ and the armature current is $18 \mathrm{~A}$ ?

Name: Problem 24, Chapter 33: Schaum’s Outline of College Physics
Uploaded: 2022-03-15T06:32:08-08:00
Duration: 1 min 40 s
Channel: Varsha Aggarwal
Description: A shunt motor develops 80 N ·m of torque when the flux density in the air gap is 1.0 Wb / m^2 and the armature current is 15 A. What is the torque when the flux density is 1.3 Wb / m^2 and the armature current is 18 A ?

   A shunt motor develops $80 \mathrm{~N} \cdot \mathrm{m}$ of torque when the flux density in the air gap is $1.0 \mathrm{~Wb} / \mathrm{m}^{2}$ and the armature current is $15 \mathrm{~A}$. What is the torque when the flux density is $1.3 \mathrm{~Wb} / \mathrm{m}^{2}$ and the armature current is $18 \mathrm{~A}$ ?

Schaum’s Outline of College Physics

Eugene Hecht 11th Edition

Chapter 33, Problem 24

Instant Answer

Solved by Expert Varsha Aggarwal

03/15/2022

Step 1

This can be expressed as: \[T \propto I \cdot B\] Show more…
