A Si n $^{+}$ p junction has an acceptor doping of $2 \times 10^{17} / \mathrm{cm}^{3}$ on the p side and crosssectional area of $10^{-2} \mathrm{~cm}^{2}$. If majority carrier lifetime is $10 \mathrm{~ns}$ and corresponding diffusion coefficient is $400 \mathrm{~cm}^{2} / \mathrm{sec}$, estimate the current density under a reverse bias of $0.3 \mathrm{~V}$ at $300 \mathrm{~K}$ temperature.

Key Concepts

Current Density Calculation

The current density in a semiconductor device is calculated by combining the charge of the carriers, their concentration, the diffusion coefficient, and the geometry of the device. In the context of reverse-biased pn junctions, this often involves using the relation J = q·(D/L)·n, where n is the minority carrier concentration, to estimate the leakage or diffusion current density.

Minority Carrier Concentration

The equilibrium concentration of minority carriers in a doped region is determined by the mass action law and is inversely proportional to the majority doping concentration. This concentration sets the baseline for the diffusion-induced current in a reverse-biased junction and is essential for estimating leakage currents.

pn Junction Reverse Bias

In a pn junction under reverse bias, the depletion region widens and the majority carrier current is suppressed, leaving a small leakage current mainly due to the transport of minority carriers. This behavior is crucial for understanding diode operation and the onset of breakdown phenomena, as well as the generation-recombination currents that can dominate in reverse-biased conditions.

Minority Carrier Diffusion

In semiconductors, minority carriers move primarily by diffusion, driven by concentration gradients. Under reverse bias, the injected minority carriers diffuse across the depletion region, and their transport is influenced by the diffusion coefficient. This process is central to analyzing leakage currents in diodes.

Diffusion Length

The diffusion length, defined as L = ?(D?), represents the average distance a carrier travels before recombining. It is a critical parameter in determining how effectively minority carriers contribute to current flow in semiconductor devices, particularly under reverse bias where diffusion governs carrier transport.
