A Si solar cell with a dark saturation current Ith of 5 nA is illuminated such that the short-ci

step 1 For this problem, we're told that the voltage, V, across part of an electric current, is given b

A Si solar cell with a dark saturation current Ith of 5 nA...

A Si solar cell with a dark saturation current $I_{\mathrm{th}}$ of $5 \mathrm{nA}$ is illuminated such that the short-circuit current is $200 \mathrm{~mA}$. Plot the $I-V$ curve for the cell as in Fig. $8-6$. (Remember that $I$ is negative, but is plotted positive as $I_{r .}$ )

Key Concepts

Dark Saturation Current

The dark saturation current is the small current that flows through a diode when it is reverse biased and in the absence of illumination. In the context of solar cells, it provides a baseline from which the photo-generated current deviates. This parameter is crucial because it influences the open-circuit voltage and overall performance of the cell, as it sets the scale for how the exponential relationship in the diode equation manifests under ambient light conditions.

I-V Curve of a Solar Cell

The I-V curve of a solar cell displays the relationship between the produced current and the voltage under various load conditions. Under illumination, the I-V curve is characterized by a negative net current due to the photo-generated current, and it is typically presented with the absolute value of current (I_r) for convenience. Key points on the curve include the short-circuit current (maximum current at zero voltage) and the open-circuit voltage (voltage at zero current). This curve is fundamental for determining parameters like fill factor and overall cell efficiency.

Short-Circuit Current

The short-circuit current is the current that flows when the solar cell’s output terminals are shorted (i.e., zero output voltage). It represents the maximum current that the cell can deliver under illumination. Since the short-circuit condition minimizes the voltage across the cell, it highlights the contribution of the photo-generated current. Understanding the short-circuit current is important for evaluating the solar cell’s performance and efficiency.

Diode Equation

The diode equation, often referred to as the Shockley diode equation, describes the current–voltage (I-V) characteristics of a diode. It relates the diode current to the applied voltage through an exponential relationship involving the dark saturation current and thermal voltage. This fundamental equation is essential for understanding how the current in a p–n junction diode behaves under both forward and reverse biases, and it serves as the basis for analyzing solar cell performance.

Photocurrent Generation

When a solar cell is illuminated, photons provide energy to generate electron-hole pairs, resulting in a photocurrent. This light-induced current, often called the photo-generated current, opposes the diode’s dark current. The net current output of the solar cell is the difference between the generated photocurrent and the dark diode current, which is why the I-V characteristic of an illuminated solar cell is a shifted version of the dark diode curve.
