A sinusoidal voltage of 40.0 V rms and a frequency of 100 Hz is applied to (a) a 100-Ωresistor

step 1 For this problem on the topic of AC circuits, we have a sinusoidal AC voltage of 40 volts RMS an

A sinusoidal voltage of 40.0 V rms and a frequency of 100...

Key Concepts

Capacitive Reactance

Capacitive reactance represents the opposition a capacitor presents to alternating current due to the electric field between its plates. It is given by X_C = 1/(2?fC), where C is the capacitance and f is the frequency. In a purely capacitive circuit, the current leads the voltage by 90°, and, similar to an inductor, an ideal capacitor does not dissipate power but only temporarily stores energy in the electric field.

Resistive Components in AC Circuits

When an AC voltage is applied to a resistor, the resistor dissipates energy as heat and there is no phase difference between the voltage and current. The current can be calculated by dividing the RMS voltage by the resistance, and the average power delivered is determined by the product of the RMS voltage and RMS current.

Inductive Reactance

Inductive reactance is the opposition that an inductor offers to an alternating current due to the magnetic field that builds up within it. It is frequency dependent and is calculated by the formula X_L = 2?fL, where f is the frequency and L is the inductance. In an ideal inductor, the current lags the voltage by 90°, and the average power over a complete cycle is zero since energy is alternately stored and released.

Peak Voltage and Its Relation to RMS

The peak value of a sinusoidal voltage is the maximum instantaneous value achieved by the waveform. For a sinusoid, this value is related to the RMS value by a factor of ?2. Understanding this relationship is important when translating between the effective and maximum amplitudes in AC analysis.

Impedance in AC Circuits

Impedance is the complex combination of resistance and reactance that a circuit presents to an alternating current. It plays a similar role to resistance in DC circuits but includes both magnitude and phase components, allowing it to account for the effects of both energy dissipation and energy storage elements in the circuit.

RMS (Root Mean Square) Voltage

The RMS voltage in an AC circuit is a measure of the effective value of a varying voltage. It is defined as the equivalent DC voltage that would deliver the same power to a resistor as the AC voltage. This concept is crucial when analyzing AC circuits because it allows engineers to work with a constant voltage value when calculating currents and power.
