A small block with mass 0.200 kg is attached to a string passing through a hole in a frictionle

step 1 Hi, here in this given problem first of all this is the horizontal surface having a hole in it.

A small block with mass 0.200 kg is attached to a string...

A small block with mass $0.200 \mathrm{~kg}$ is attached to a string passing through a hole in a frictionless, horizontal surface(see Fig. E10.42). The block is originally revolving in a circle with a radius of $0.790 \mathrm{~m}$ about the hole with a tangential speed of $3.70 \mathrm{~m} / \mathrm{s}$. The string is then pulled slowly from below, shortening the radius of the circle in which the block revolves. The breaking strength of the string is $31.0 \mathrm{~N}$. What is the radius of the circle when the string breaks?

Key Concepts

Conservation of Angular Momentum

Conservation of angular momentum states that when no external torque acts on a system, the angular momentum remains constant. For a mass moving in a circle, the angular momentum L is given by m*v*r. When the radius changes and there are no external torques, the speed must adjust inversely with the radius to conserve angular momentum. This principle is key in problems where the radius of rotation changes, affecting the speed of the revolving object.

Tension in a String

Tension in a string refers to the pulling force transmitted along the string that provides the necessary centripetal force for circular motion. In systems involving a mass attached to a string, the maximum allowable tension (breaking strength) limits the dynamics of the motion. Understanding this concept is critical when determining how changes in the system, such as a decreasing radius, affect the force in the string and ultimately its structural integrity.

Centripetal Force

Centripetal force is the net inward force required to keep an object moving in a circular path. It is given by the formula F = m*v^2/r, where m is the mass, v is the tangential speed, and r is the radius of the circle. This concept is essential for understanding the dynamics of any object in circular motion, as it explains why the object continuously changes direction, keeping it on a curved path.
