A specification sheet provides the following data (at a listed drain-source current):
$$
g_{f s}=4.5 \mathrm{mS}, \quad g_{o s}=25 \mu \mathrm{S}
$$
At the listed drain-source current, determine:
a. $g_{m}$
1

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Transconductance (g_m)

Transconductance is a key parameter in active devices like MOSFETs that quantifies the change in the drain current for a given change in the gate voltage while keeping the drain-source voltage constant. It is essential in determining the amplification property of a transistor in analog circuits.

Small-Signal Model

The small-signal model is an approach used in circuit analysis where a nonlinear device is approximated by linear parameters around its operating (bias) point. This model includes parameters such as transconductance and output conductance, making it possible to analyze the response of the transistor to small input variations.

Output Conductance

Output conductance is defined as the rate of change of the drain current with respect to the drain-source voltage at a constant gate voltage. It provides insight into how the device current varies with drain voltage, and it plays a crucial role in determining the output resistance of the device in the small-signal analysis.
