A spherical balloon has an initial diameter of $1 \mathrm{m}$ and contains argon gas at $200 \mathrm{kPa}, 40^{\circ} \mathrm{C}.$ The balloon is connected by a valve to a $500-\mathrm{L}$ rigid tank containing carbon dioxide at $100 \mathrm{kPa}$ $100^{\circ} \mathrm{C} .$ The valve is opened, and eventually the balloon and tank reach a uniform state in which the pressure is $185 \mathrm{kPa}$. The balloon pressure is directly proportional to its diameter. Take the balloon and tank as a control volume, and calculate the final temperature and the heat transfer for the process.

Key Concepts

Ideal Gas Law

This is the fundamental relationship among pressure, volume, and temperature in a gas. It allows us to describe and predict the behavior of gases under various conditions, and in this type of problem, it is used to calculate the number of moles and the state of each gas before and after mixing.

Control Volume Analysis

This technique involves considering a fixed region in space (the combined balloon and tank, in this case) and applying conservation principles, such as mass and energy balances, to that region. It simplifies complex systems by tracking the inflow and outflow of properties within a well?defined boundary.

First Law of Thermodynamics

This principle, that energy cannot be created or destroyed but only transferred or converted, is used to set up an energy balance for the system. For a closed control volume, it equates the change in internal energy to the net heat transfer and work interactions that occur during the process.

Elasticity of Flexible Containers

In systems where the container (like the balloon) is flexible, the pressure and volume relationship can be influenced by the elastic properties of the material. Here, the fact that the balloon’s pressure is directly proportional to its diameter introduces a non?standard relationship that must be considered when calculating work and energy transfer.

Gas Mixing

Mixing of different gases involves combining gases that may initially be at different temperatures, pressures, and compositions. When they mix in a closed system, energy and mass conservation principles are applied to determine the final equilibrium state, accounting for the effect of differences in gas properties on the overall process.
