A steam radiator in a room at 75 F has saturated water vapor...

A steam radiator in a room at 75 F has saturated water vapor at 16 lbf/in $^{2}$ flowing through it when the inlet and exit valves are closed. What is the pressure and the quality of the water when it has cooled to 75 F? How much work is done?

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Closed System Cooling

In a closed system, no mass enters or leaves during a process, which means that any cooling or heating occurs at constant mass. When a closed system is cooled, the state of the substance can change (for example, from saturated vapor to a mixture with increasing liquid fraction) while other properties, like volume, are constrained.

Work in Constant Volume Processes

Work in thermodynamic processes is typically associated with volume changes. In a process where the volume is held constant (a rigid or closed container), there is no boundary work done because the integration of pressure with respect to volume change results in zero work, regardless of changes in other state properties.

Saturation Properties

Saturation properties describe the conditions at which a substance exists in equilibrium between its liquid and vapor phases. At a given pressure or temperature, the saturation point is where both phases coexist, and these relationships are typically found in property tables or steam tables.

Quality of a Mixture

Quality (often symbolized as x) is the fraction of the total mass of a two-phase liquid-vapor mixture that is in the vapor phase. It ranges from 0 (completely liquid) to 1 (completely vapor) and is a key parameter for understanding phase changes during processes such as condensation or evaporation.
