A steam turbine is operated with an intake temperature of 400^∘ C, and an exhaust temperature of

step 1 So let's solve this question. So in this question, we have T .E equals to P .I. P .I. Rest to po

A steam turbine is operated with an intake temperature of...

A steam turbine is operated with an intake temperature of $400^{\circ} \mathrm{C}$, and an exhaust temperature of $150^{\circ} \mathrm{C}$. What is the maximum amount of work the turbine can do for a given heat input $Q$ ? Under what conditions is the maximum achieved?

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Carnot Efficiency

Carnot efficiency is the theoretical upper limit on the performance of a heat engine operating between two thermal reservoirs. It is defined as the ratio 1 - (T_c/T_h), where T_c and T_h are the absolute temperatures of the cold and hot reservoirs respectively. This concept illustrates that no engine can convert heat into work more efficiently than a Carnot engine operating between the same temperature limits.

Reversible Processes

A reversible process in thermodynamics is an idealized process that occurs without any entropy generation or energy dissipation, meaning it can be reversed without leaving any net change in the Universe. For maximum work output, systems must operate reversibly since any irreversibility (due to friction, turbulence, etc.) leads to lost work potential compared to the ideal case.

Maximum Work in Heat Engines

The concept of maximum work in heat engines is rooted in the application of the Carnot cycle, where the maximum possible work is produced when a fixed amount of heat is transferred reversibly between the hot and cold reservoirs. Mathematically, the maximum work is given by Q × (1 - T_c/T_h), achieved under ideal reversible conditions with all heat inputs and rejections occurring exactly at the specified reservoir temperatures.
