A student who's confused about voltage and current hooks a...

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Safety Hazards

Improper measurement or connection of instruments, such as connecting an ammeter directly across a voltage source, can result in dangerous situations. The resulting high current due to the creation of a near-short circuit can lead to overheating, component damage, or even fire, emphasizing the need for careful circuit measurement practices.

Short Circuit

A short circuit occurs when a very low-resistance path is connected across a power source, causing an abnormally high current to flow. This condition bypasses the normal load resistance and can lead to damage or hazardous conditions due to the excessive flow of current.

Ammeter

An ammeter is a device used to measure current in a circuit and is designed to have extremely low resistance so that it minimally affects the circuit. It is typically connected in series with the load to accurately sense current flow without introducing significant voltage drops.

Internal Resistance

Internal resistance is the inherent resistance present within a power source, such as a battery, which limits the maximum current that can flow during conditions like a short circuit. Even when an external device offers negligible resistance, the battery’s internal resistance will determine the upper bound of the current.
