(a) Suppose you are given three springs with respective stiffnesses $c=1, c^{\prime}=2, c^{\prime \prime}=3$. In what order should you connect them to three masses and a top support so that the bottom mass goes down the farthest under a uniform gravitational force? (b) Answer Exercise 6.1.8 when the springs connect two masses to top and bottom supports.

(a) Suppose you are given three springs with respective stiffnesses $c=1, c^{\prime}=2, c^{\prime \prime}=3$. In what order should you connect them to three masses and a top support so that the bottom mass goes down the farthest under a uniform gravitational force?
(b) Answer Exercise 6.1.8 when the springs connect two masses to top and bottom supports.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Series Spring Systems

In a series arrangement of springs, the same force acts through each spring and the total displacement is the sum of the individual displacements, with each displacement being inversely proportional to the spring’s stiffness (extension = force/stiffness). This principle allows one to determine the effective displacement of a system by considering how each spring’s placement affects the overall movement.

Load Distribution in Multi?Mass Systems

In multi?mass systems, the gravitational force accumulates along the chain. The spring nearer to the top bears the weight of all masses below it, whereas springs lower in the chain support fewer masses. This differential loading means that the displacement produced by a given spring depends not only on its stiffness but also on the number of masses (and thus the total weight) it supports.

Optimization of Spring Order

When the goal is to maximize the displacement of a specific mass in a chain, one must strategically assign springs with different stiffness values to positions where the force acting through each is optimally paired. For instance, placing a softer (less stiff) spring in a position where the force is highest can yield a greater extension, while a stiffer spring might be better positioned where it supports less load.
