A tension test was performed on a steel specimen having an...

A tension test was performed on a steel specimen having an original diameter of 0.503 in. and gage length of 2.00 in. The data is listed in the table. Plot the stress-strain diagram and determine approximately the modulus of clasticity, the yield stress, the ultimate stress, and the fracture stress. Use a scale of 1 in. $=20$ ksi and 1 in. $=0.05$ in. $/$ in. Redraw the elastic region, using the same stress scale but a strain scale of 1 in. $=0.001$ in. $/$ in.

Key Concepts

Yield Stress

Yield stress is the stress level at which a material transitions from elastic behavior to plastic deformation, where permanent changes in shape occur. Identifying the yield point on the stress-strain curve is essential for understanding the material's performance limits under load.

Fracture Stress

Fracture stress is the stress at which a material ultimately fails and fractures. This point on the stress-strain diagram marks the termination of the test, where the accumulated damage leads to material rupture.

Modulus of Elasticity

The modulus of elasticity, also known as Young's modulus, is a measure of a material’s stiffness in the elastic region. It is determined from the slope of the initial linear portion of the stress-strain curve where the material deforms elastically and returns to its original shape upon load removal.

Ultimate Tensile Strength

The ultimate tensile strength (UTS) is the maximum stress a material can sustain before necking and eventual failure occur. It is identified as the peak point on the stress-strain curve and indicates the maximum load-bearing capability of the material.

Strain

Strain is a measure of deformation representing the relative displacement between particles in a material compared to its original length. It quantifies how much a material stretches or compresses under an applied load and is expressed as a dimensionless ratio.

Tensile Testing

Tensile testing is an experimental procedure used to evaluate the mechanical properties of a material by applying a uniaxial force until the specimen fractures. It is a fundamental method for determining strength, ductility, and stiffness—key factors in material selection and engineering design.

Stress-Strain Curve

The stress-strain curve is a graphical representation showing the relationship between stress and strain as a material is deformed under loading. This curve provides valuable insights into material behavior, including elastic deformation, yield point, plastic deformation, ultimate tensile strength, and fracture point.

Stress

Stress is defined as the internal force per unit area within materials that arises from externally applied forces. It is a core concept in mechanics used to predict how materials will react under different loads and is typically expressed in units such as psi or ksi.
