A trap door in a ceiling is 0.91 m square, has a mass of 11 kg, and is hinged along one side, wi

step 1 So here, for Part A, we're going to set up the equilibrium of torques. This leads to a simple le

A trap door in a ceiling is 0.91 m square, has a mass of 11...

A trap door in a ceiling is 0.91 $\mathrm{m}$ square, has a mass of 11 $\mathrm{kg}$, and is hinged along one side, with a catch at the opposite side. If the center of gravity of the door is 10 $\mathrm{cm}$ toward the hinged side from the door's center, what are the magnitudes of the forces exerted by the door on (a) the catch and (b) the hinge?

Key Concepts

Center of Gravity

The center of gravity is the effective point at which the entire weight of the object can be considered to act. In this context, knowing the exact location of the center of gravity is crucial because it determines the torque produced by the gravitational force about the hinge. A shift in the center of gravity affects the balance of moments and thus the distribution of reaction forces at the catch and the hinge.

Reaction Forces

Reaction forces are the forces exerted by supports or connections that prevent the structure from moving. In the case of the door, the hinge and catch provide reaction forces to counteract the gravitational torque. Understanding these forces is key to determining how the weight of the door and the distribution of mass translate into forces at the pivot points.

Static Equilibrium

This concept refers to a state where an object is at rest or moving with a constant velocity, meaning that the net force and the net torque (moment) acting on it are zero. In problems like this, where the door is in a balanced configuration under gravity, the sum of the forces and the sum of the moments about any pivot (such as the hinge) must cancel out. This ensures that the object does not translate or rotate undesirably.

Torque (Moment of Force)

Torque is the rotational equivalent of force, determined by the product of the force and the perpendicular distance from the pivot to the line of action of the force. In such scenarios, different forces (like the door's weight acting through its center of gravity, the force at the catch, and the hinge reactions) create torques which must balance each other for the door to remain in equilibrium.
