00:01
Hello and welcome to this video solution of numerate.
00:04
So here you have to draw the following waves right based on the given shapes right.
00:14
So a you have got a triangular wave of period t which is five milliseconds and amplitude of two right.
00:21
Okay so what you can do is you can plug in the value of the amplitude and the time period or t and the wave will be sort of like this.
00:32
It's a triangular wave right.
00:35
This amplitude is two meters and this time is five milliseconds.
00:42
So this is five milliseconds right.
00:44
So from the initial to the final point again that's initial point for this second wave right.
00:53
So this is a now b.
00:57
B is a square wave of period t and amplitude of three right.
01:11
So it's pretty simple again the same you have to draw it here.
01:17
Now a square wave right.
01:19
So sort of like this you start from this is a square wave and on the other side you can extend the second square right.
01:27
So here you have got an amplitude of two sorry this is three meters.
01:37
This is amplitude or maybe you can write this is y this is not this is y and this is t right...
