A turbine is developing 7500 kW at 6000 rpm (see Fig, P.14.8). For an allowable shear stress of $1 \times 10^8 \mathrm{~Pa}_3$, what should be the diameter $D_1$ of the shaft transmitting torque from the turbine to the reduction gear system? If the reduction in speed is 100 to 1 , what should be the diameter $D_2$ of the shaft between the reduction gears and the gencrator? Figure P.148.

Key Concepts

Gear Reduction and Its Effects on Shaft Design

Gear reduction alters the speed and torque transmitted through the system. A reduction in speed by a certain ratio, such as 100:1, typically results in a proportional increase in torque on the output side of the gear system. This increased torque must be accounted for in the design of the subsequent shaft to ensure it is sized appropriately to handle the higher load without exceeding allowable stresses.

Torsional Shear Stress in Shafts

This concept involves understanding how a shaft subjected to an applied torque develops shear stresses across its cross-section. The distribution of shear stress in a circular shaft is governed by the torsion formula, where the torque, polar moment of inertia, and shaft radius determine the resulting stress. Designers must ensure that the maximum shear stress does not exceed the allowable limit for the material.

Power, Torque, and Rotational Speed Relationship

In mechanical systems, power, torque, and rotational speed are directly related. The formula connecting these quantities enables the calculation of the torque transmitted by a shaft given a specific power output and rpm. This relationship is critical in converting the energy produced by a turbine or engine into the mechanical force needed to drive rotating machinery while keeping the stresses within safe limits.

Shaft Diameter Design

The design of a shaft for transmitting torque involves selecting an appropriate diameter such that the induced shear stresses do not surpass the material’s allowable stress. Calculation of the required shaft diameter takes into account the applied torque, the geometry of the shaft (through the polar moment of inertia), and the desired safety margin, ensuring structural integrity under operating conditions.
