A type 316 stainless steel bar is $20 \mathrm{~cm}$ long, $3 \mathrm{~cm}$ wide, and $4 \mathrm{~mm}$ thick. Water at $20^{\circ} \mathrm{C}$ impinges on each side face of the bar, giving a convective heat transfer coefficient of $6500 \mathrm{~W} / \mathrm{m}^{2} \mathrm{~K}$. The initial temperature of the bar is also $20^{\circ} \mathrm{C}$, and at time $t=0$ an electric current is passed through the bar, giving a volumetric heat generation of $86.7 \mathrm{MW} / \mathrm{m}^{3}$. (i) Derive explicit finite-difference approximations for nodes $T_{0}, T_{1}$, and $T_{2}$. (ii) For the given mesh, calculate the nodal temperatures for the first four time steps by the explicit method. Use a Fourier number of $0.3$ but show that it satisfies the appropriate stability criterion.

A type 316 stainless steel bar is $20 \mathrm{~cm}$ long, $3 \mathrm{~cm}$ wide, and $4 \mathrm{~mm}$ thick. Water at $20^{\circ} \mathrm{C}$ impinges on each side face of the bar, giving a convective heat transfer coefficient of $6500 \mathrm{~W} / \mathrm{m}^{2} \mathrm{~K}$. The initial temperature of the bar is also $20^{\circ} \mathrm{C}$, and at time $t=0$ an electric current is passed through the bar, giving a volumetric heat generation of $86.7 \mathrm{MW} / \mathrm{m}^{3}$.
(i) Derive explicit finite-difference approximations for nodes $T_{0}, T_{1}$, and $T_{2}$.
(ii) For the given mesh, calculate the nodal temperatures for the first four time steps by the explicit method. Use a Fourier number of $0.3$ but show that it satisfies the appropriate stability criterion.

Key Concepts

Finite Difference Approximation

This concept involves discretizing continuous differential equations into algebraic equations using a grid (mesh) of nodes. Differences in temperature between nodes are used to approximate derivatives, transforming the heat equation into a system of algebraic equations that are easier to solve numerically. This method allows one to model spatial variations and time evolution in a medium by replacing derivatives with finite differences over small intervals.

Explicit Time Integration Method

The explicit method is a time-stepping numerical technique where the state of a system at a future time is calculated directly from the known information at the current time step. In the context of heat conduction, it means that the temperature at each node at the next time step is computed explicitly from the temperatures at the current time level. This method is straightforward to implement but requires careful control of the time step size to maintain stability.

Stability Criterion and Fourier Number

The stability criterion for explicit finite difference methods is commonly expressed in terms of the Fourier number, a dimensionless number that characterizes the ratio of diffusive to storage effects in a material. For stability, the Fourier number (which depends on the thermal diffusivity, time step, and spatial discretization size) must typically be below a critical value. In explicit heat conduction problems, ensuring that the Fourier number remains small helps prevent numerical instabilities that could lead to nonphysical solutions.

Convective Boundary Conditions

Convective boundary conditions account for heat transfer at the surface of a material due to convection with an adjacent fluid. In a finite difference scheme, these conditions require special treatment at the boundary nodes to incorporate the effect of the convective heat transfer coefficient. This involves modifying the finite difference equations at the boundaries to include heat losses (or gains) due to the fluid motion at the interface.

Volumetric Heat Generation

This concept introduces an internal source term into the heat conduction problem, representing the generation of heat within the volume of the material. In the finite difference method, the term for internal heat generation is added to the discretized heat equation, affecting the temperature evolution at each node. Handling internal heat generation accurately is important when the energy is produced within the solid rather than being applied solely through the boundaries.
