A uniform cube of mass m and edge a moves on a horizontal...

A uniform cube of mass $m$ and edge $a$ moves on a horizontal surface along the positive $x$ -axis, with initial velocity $v_{0}$ : (a) during motion, $N>m g$ (b) during motion, normal reaction acts on the centre of mass (c) during motion, the normal reaction shifts towards positive $x$ -axis from the centre of mass (d) during motion, normal reaction shifts in the direction of the forces of friction

A uniform cube of mass $m$ and edge $a$ moves on a horizontal surface along the positive $x$ -axis, with initial velocity $v_{0}$ :
(a) during motion, $N>m g$
(b) during motion, normal reaction acts on the centre of mass
(c) during motion, the normal reaction shifts towards positive $x$ -axis from the centre of mass
(d) during motion, normal reaction shifts in the direction of the forces of friction

Key Concepts

Normal Reaction Force

This concept deals with the force exerted by a surface to support the weight of a body in contact with it. In dynamics problems involving solid bodies, the normal force may not remain strictly equal to the gravitational force if the body experiences additional accelerations or torques. The distribution or point of application of the normal force can shift to satisfy the conditions of equilibrium, especially when friction or inertial effects are present.

Centre of Mass

The centre of mass of an object is the point at which its mass can be considered to be concentrated for the analysis of translational motion. In rigid body dynamics, external forces such as gravity act through the centre of mass, and analyzing how other forces (like friction and the normal reaction) relate to this point is vital in understanding both the translational and rotational behaviour of the object.

Frictional Forces in Rigid Body Dynamics

Friction is the resistive force acting parallel to the contact surface which opposes relative motion between bodies. When a rigid body, like a cube, slides along a surface, friction not only decelerates the centre of mass but may also produce a torque that affects rotational motion. Analyzing how friction interacts with the normal force is key in determining shifts in the overall force distribution during motion.

Torque and Moment Equilibrium

In addition to linear forces, the rotational effects (torques) produced by forces acting at various points on a rigid body must be considered. The combined effect of frictional forces and the shifted line of action of the normal force can create torques that influence the body's rotational state. Establishing moment equilibrium helps in understanding how the resultant force aligns with respect to the centre of mass, ensuring that the body’s motion is correctly described by both translational and rotational dynamics.
