A uniform cubical crate is 0.750 $\mathrm{m}$ on each side and weighs 500 $\mathrm{N}$ . It rests on a floor with one edge against a very small, fixed obstruction. At what least height above the floor must a horizontal force of magnitude 350 $\mathrm{N}$ be applied to the crate to tip it?

A uniform cubical crate is 0.750 $\mathrm{m}$ on each side and weighs 500 $\mathrm{N}$ . It rests on a floor with one edge against a very small, fixed
obstruction. At what least height above the floor must a horizontal
force of magnitude 350 $\mathrm{N}$ be applied to the crate to tip it?

Key Concepts

Center of Mass

The center of mass is the point at which the mass of an object can be considered to be concentrated, and for uniform objects it coincides with the geometric center. The gravitational force acting through the center of mass creates a resisting torque when the object is subjected to forces attempting to tip it. Understanding the location of the center of mass is key to analyzing the balance of moments in tipping scenarios.

Rotational Equilibrium

Rotational equilibrium occurs when the sum of all torques acting on an object about any pivot point is zero, meaning there is no net rotational acceleration. In tipping problems, determining the point at which the applied torque equals the resisting torque from weight results in the threshold condition for the onset of tipping. Establishing rotational equilibrium is fundamental to calculating the minimum force or force application height required to initiate tipping.

Torque

Torque is the measure of a force's tendency to produce rotation about a pivot or axis. It is calculated as the product of the force and the perpendicular distance (lever arm) from the pivot point at which the force is applied. In problems involving tipping, comparing the torques generated by different forces is essential to determine whether the applied force will overcome the resisting moments, such as those provided by gravitational forces acting at the center of mass.

Moment Arm

The moment arm is the perpendicular distance between the line of action of a force and the pivot point about which rotation occurs. It is crucial in calculating the torque generated by a force. In tipping problems, increasing the moment arm by applying the force higher on the object can make the applied force more effective at overcoming the resisting torque due to the object's weight.
