A uniform slender bar of length $L=200 \mathrm{mm}$ and mass $m=0.5 \mathrm{kg}$ is supported by a frictionless horizontal table. Initially the bar is spinning about its mass center $G$ with a constant angular speed $\omega_{1}=6 \mathrm{rad} / \mathrm{s}$. Suddenly latch $D$ is moved to the right and is struck by end $A$ of the bar. Knowing that the coefficient of restitution between $A$ and $D$ is $e=0.6$, determine the angular velocity of the bar and the velocity of its mass center immediately after the impact.

Key Concepts

Angular Momentum Conservation

This principle states that when no external torques act on a system, its total angular momentum remains constant. In the context of collisions in rigid body dynamics, it is used to relate the rotational states before and after an impact, allowing for the analysis of changes in angular velocity resulting from impulsive forces.

Moment of Inertia

The moment of inertia is a measure of a body's resistance to changes in its rotational motion about a given axis. For a uniform slender bar, it is essential for connecting the angular velocity and the rotational kinetic energy, and it plays a key role in understanding how the mass distribution affects the dynamics during and after an impact.

Coefficient of Restitution

The coefficient of restitution quantifies the elasticity of a collision, defining the ratio of the relative speed after collision to that before collision along the line of impact. This concept is crucial in impact problems as it governs the amount of kinetic energy dissipated and helps determine the final translational and rotational velocities of the body.

Impulsive Forces and Impact Dynamics

Impulsive forces are those acting over very short time intervals during collisions, resulting in sudden changes in momentum. In rigid body dynamics, especially in frictionless environments, these forces can produce both translational and rotational changes, making it essential to consider their effect for accurately predicting post-impact motion.

Transcript

00:04 In this problem, we need to solve for the angular velocity of the bar and the velocity of its mass center upon impact.

00:12 So i have here a sketch of the problem.

00:15 So the bar with mass m, so 5 kilograms, initially rotating at angular velocity omega -1 with the value of 6 regions per second, hits a latch producing an impulse at point a.

00:30 So as you can see in the second part of the diagram.

00:34 Causing it to rotate with a different angular velocity omega 2 and move its center of mass to move with a linear velocity v2 so as you can see in the last part of the sketch and as you know we can express the linear velocity in terms of r and omega so for the velocity before the impact so the velocity the linear velocity of point a so b a 1 is given by so l over 2 omega sub 1 so this is directed downward so since the bar rotates about the center point g which is at a distance of l over 2 away and it's downward because as you can see in the sketch we assume that it's initially rotating in the counterclockwise direction now after the impact the velocity at point a so b a 2 is equal to negative e v a 1 so where e here is the coefficient of restitution so substituting the equation for v a 1 so this would be equal to so l over 2 e omega sub 1 so this is pointed upward so we omit the negative sign there so since as you can see in the diagram the bar rotates in the opposite direction after impact so hence the linear velocity v2 after the impact is equal to so v a2 plus l over 2 omega 2 so substituting the equation for b a 2 so we'll have so one half l e omega 1 plus 1 half l omega 2 so applying the impulse momentum theorem and solving for the moments about point d, taking the counterclockwise direction as positive, so we'll have, so i omega 1 plus 0 equals i omega 2 plus m v square, v2, sorry, l over 2.

02:57 So we can substitute now the equation for v2 that we have earlier.

03:04 So this becomes i omega 1 equals i omega 2 plus m times 1 half e l omega 1 plus 1⁄2 times l omega 2 times l over 2.

03:25 Then we can replace i here with the equation for the moment of inertia...
