A V-shaped painted steel channel, similar to Fig. E10.6 has an included angle of $90^{\circ} .$ If the slope, in uniform flow, is $3 \mathrm{m}$ per $\mathrm{km}$, estimate $(a)$ the flow rate, in $\mathrm{m}^{3} / \mathrm{s}$ and $(b)$ the average wall shear stress. Take $y=2 \mathrm{m}$.

A V-shaped painted steel channel, similar to Fig. E10.6 has an included angle of $90^{\circ} .$ If the slope, in uniform flow, is $3 \mathrm{m}$ per $\mathrm{km}$, estimate $(a)$ the flow rate, in $\mathrm{m}^{3} / \mathrm{s}$ and
$(b)$ the average wall shear stress. Take $y=2 \mathrm{m}$.

Key Concepts

Energy Slope

The energy slope represents the rate of energy loss per unit length along the channel and, in uniform flow conditions, is equal to the channel bed slope. It is a critical factor in determining both the flow velocity and the wall shear stress within the channel.

Manning’s Equation

Manning’s equation is an empirical formula used to estimate the flow rate in open channels by relating the channel geometry, hydraulic radius, slope, and a roughness coefficient. It provides a practical way to predict discharge under uniform flow conditions.

Wall Shear Stress

Wall shear stress is the frictional force per unit area exerted by the fluid on the channel boundaries. It is influenced by the hydraulic radius, fluid density, gravity, and the channel slope. Estimating wall shear stress is important in evaluating the potential for material wear and structural integrity of the channel boundaries.

Open Channel Flow Geometry

The channel’s cross-sectional shape, such as a V-shaped or trapezoidal channel, is essential in determining the flow area and the wetted perimeter. These geometric properties directly influence the calculation of hydraulic radius and, ultimately, the flow rate and wall shear stress.

Uniform Flow

Uniform flow refers to a condition in an open channel where the water depth, velocity, and flow rate remain constant along the length of the channel. This implies that gravitational driving forces are exactly balanced by frictional forces, so the energy slope equals the channel bed slope, simplifying the analysis of the flow characteristics.

Hydraulic Radius

Hydraulic radius is defined as the cross-sectional area of the flow divided by the wetted perimeter and is a key parameter in describing the efficiency of the channel in conveying water. It is used to quantify the effect of channel shape on friction losses and is fundamental in flow resistance equations.
