A wave is described by the expression $y(x, t)=(3.0 \mathrm{~cm}) \times$ $\cos (1.5 x-50 t),$ where $x$ is in $m$ and $t$ is in $s .$
a. Draw an accurate snapshot graph of this wave.
b. What is the speed of the wave and in what direction is it traveling?

Key Concepts

Graphical Representation of a Wave

Graphing a traveling wave involves creating a snapshot of the wave at a specific point in time to visualize its spatial variation. The graph typically shows a periodic oscillation, allowing one to observe characteristics like wavelength and amplitude, and helps in understanding how the wave would evolve or move over time.

Phase Velocity

Phase velocity is the speed at which a specific phase of the wave, such as the crest, travels through space. It is determined by the ratio of the angular frequency to the wave number (v = ?/k) and provides insight into the direction and speed of propagation of the wave.

Wave Number and Angular Frequency

The wave number (k) and angular frequency (?) are fundamental parameters in describing a sinusoidal wave. The wave number is related to the wavelength and indicates how rapidly the wave oscillates in space, while the angular frequency is related to the time period and indicates how rapidly the wave oscillates in time.

Amplitude

Amplitude refers to the maximum displacement of points on a wave from its equilibrium position. It is a measure of the energy contained in the wave, with larger amplitudes indicating higher energy.

Wave Equation

The wave equation is a mathematical representation of a wave as a function of position and time. In its sinusoidal form, it typically includes parameters like amplitude, wave number, and angular frequency. The equation helps in analyzing how the wave propagates and changes with respect to space and time.

Traveling Wave

A traveling wave is a disturbance that moves through a medium, transferring energy from one location to another without transporting matter permanently. It is typically described using a function that depends on both space and time, and its behavior is characterized by properties like amplitude, wavelength, frequency, and speed.
