Air flows through the venturi meter described in Problem $8.195 .$ Assume that the upstream pressure is 60 psi. and that the temperature is everywhere constant at $68^{\circ} \mathrm{F}$ Determine the maximum possible mass flow rate of air for which the assumption of incompressible flow is a valid engineering approximation. Compute the corresponding differential pressure reading on a mercury manometer.

Key Concepts

Venturi Meter

A Venturi meter is a flow measurement device that uses a converging section and a throat to create a pressure difference between two points in a pipe. This pressure difference is related to the velocity of the fluid by Bernoulli’s principle, allowing the flow rate to be determined. It is widely used due to its relatively simple design and accuracy over a range of conditions.

Bernoulli’s Principle

Bernoulli’s principle relates the pressure, velocity, and elevation of a fluid in steady, streamline flow. In the context of a Venturi meter, it explains how a reduction in cross-sectional area leads to an increase in fluid velocity and a corresponding drop in pressure. This relationship is fundamental for converting pressure measurements into flow rates.

Incompressible Flow Approximation

The incompressible flow assumption simplifies fluid dynamics analysis by assuming the fluid density remains constant throughout the flow. This assumption is particularly valid for liquids and for gases flowing at low Mach numbers (typically below 0.3), where pressure changes do not significantly affect density. It is an essential approximation for accurate and manageable engineering calculations in many applications.

Compressibility Effects in Gases

Compressibility effects become important when the variations in pressure and velocity are significant enough to affect a gas’s density. In flow measurement scenarios, if the Mach number exceeds a certain threshold, the assumption of constant density breaks down, requiring more complex models that account for compressibility. Identifying the limit for using the incompressible approximation in gas flow is crucial for ensuring the validity of the analysis.

Manometer Differential Pressure Reading

A manometer is an instrument used to measure pressure differences, often employing a column of fluid such as mercury. The differential height of the mercury column corresponds to a pressure difference based on the fluid’s density and gravitational acceleration. This measurement technique is key in diagnostics and calibrations in systems where pressure drops are used to infer flow characteristics.
