Aluminum extrusions, patterned after NACA symmetric airfoil sections, frequently are used to form Darrieus wind turbine "blades." Below are section lift and drag coefficient data [57] for a NACA 0012 section, tested at $R e=6 \times 10^{6}$ with standard roughness (the section stalled for $\left.\alpha>12^{\circ}\right)$ Analyze the air flow relative to a blade element of a Darrieus wind turbine rotating about its troposkien axis. Develop a numerical model for the blade element. Calculate the power coefficient developed by the blade element as a function of tip-speed ratio. Compare your result with the general trend of power output for Darrieus rotors shown in Fig. 10.50

Aluminum extrusions, patterned after NACA symmetric airfoil sections, frequently are used to form Darrieus wind turbine "blades." Below are section lift and drag coefficient data [57] for a NACA 0012 section, tested at $R e=6 \times 10^{6}$ with standard roughness (the section stalled for $\left.\alpha>12^{\circ}\right)$
Analyze the air flow relative to a blade element of a Darrieus wind turbine rotating about its troposkien axis. Develop a numerical model for the blade element. Calculate the power coefficient developed by the blade element as a function of tip-speed ratio. Compare your result with the general trend of power output for Darrieus rotors shown in Fig. 10.50

Key Concepts

Airfoil Aerodynamics

Airfoil aerodynamics focuses on how the shape and orientation of an airfoil affect its interaction with airflow. This includes analyzing lift and drag forces generated by the airfoil, understanding how these forces change with angle of attack, and considering factors like stall and flow separation. It is essential for predicting performance under various flow conditions and is fundamental when designing or analyzing aerodynamic surfaces used in wind turbine blades.

Blade Element Theory

Blade element theory is a method used to break down a wind turbine blade into a series of small, independent elements. Each element’s aerodynamic forces are calculated based on local flow conditions, including relative wind speed and angle. The cumulative effect of these forces along the span of the blade is then integrated to predict overall performance characteristics such as torque and power output. This theory is crucial in the design and analysis of rotating blades, providing a simplified yet effective approach to model complex aerodynamic phenomena.

Lift and Drag Coefficients

Lift and drag coefficients are dimensionless parameters that quantify the lift and drag forces generated by an airfoil relative to the dynamic pressure of the fluid flow and the airfoil's characteristic area. These coefficients are measured or predicted over a range of angles of attack and are key inputs in aerodynamic calculations. Their accurate determination is critical for modeling the performance of wind turbine blades under varying conditions, influencing efficiency, stability, and the onset of stall.

Tip-Speed Ratio

The tip-speed ratio is the ratio of the speed of the tip of a wind turbine blade to the free-stream wind speed. It is an essential parameter in wind turbine design because it influences the aerodynamic efficiency and overall performance of the turbine. A high tip-speed ratio generally improves efficiency but may also increase noise and stresses on the structure, while a lower tip-speed ratio might be easier on materials but less efficient in energy capture.

Power Coefficient

The power coefficient is a measure of the efficiency with which a wind turbine converts the kinetic energy in the wind into mechanical power. It is defined as the ratio of the power extracted by the turbine to the total available wind power. Understanding and calculating the power coefficient as a function of parameters such as tip-speed ratio is vital for comparing different turbine designs and optimizing performance.

Numerical Modeling

Numerical modeling involves using computational methods to simulate the aerodynamic behavior of wind turbine blades. This includes solving equations of fluid dynamics around the blade element, integrating local contributions along the blade span, and predicting overall performance metrics such as power output. Numerical models help validate theoretical predictions and provide insights into complex interactions that are difficult to capture analytically, making them an indispensable tool in modern wind turbine design and analysis.
