An abrupt silicon pn junction at zero bias has dopant...

An abrupt silicon pn junction at zero bias has dopant concentrations of $N_{a}=10^{17} \mathrm{~cm}^{-3}$ and $N_{d}=5 \times 10^{15} \mathrm{~cm}^{-3} . T=300 \mathrm{~K}$. (a) Calculate the Fermi level on each side of the junction with respect to the intrinsic Fermi level. (b) Sketch the equilibrium energyband diagram for the junction and determine $V_{b i}$ from the diagram and the results of part $(a) .(c)$ Calculate $V_{b i}$ using Equation $(7.10)$, and compare the results to part $(b) .$ (d) Determine $x_{m}, x_{n}$, and the peak electric field for this iunction.

Key Concepts

Depletion Region Analysis

The depletion region in a p-n junction is the area where mobile charge carriers have been swept out, leaving behind fixed ionized dopants. Analyzing this region involves calculating its width on both sides of the junction (commonly denoted as x_n for n-side and x_m for p-side) as well as determining the peak electric field within it. This analysis helps in understanding the electric field distribution that is essential for device functionality such as rectification and breakdown phenomena.

Equilibrium Energy Band Diagram

An equilibrium energy band diagram graphically represents the alignment of the conduction and valence bands across a p-n junction when no external bias is applied. It shows how the energy bands bend due to the built-in potential and indicates the positions of the Fermi levels on both sides. This diagram is an essential tool for understanding carrier behavior, energy barriers for carrier movement, and the overall operation of semiconductor devices.

Fermi Level Positioning

This concept involves determining the relative position of the Fermi level with respect to the intrinsic Fermi level in a semiconductor. In doped semiconductors, the Fermi level shifts depending on the type and level of dopants; in p-type material it lies below the intrinsic level, and in n-type material it lies above. Calculating these positions requires the use of the mass action law and knowledge of the doping concentrations, which ultimately provides insight into the carrier concentrations and electrical properties of the semiconductor.

Intrinsic Fermi Level

The intrinsic Fermi level is the energy level at which the probability of occupancy by an electron is 50% in an undoped, pure semiconductor. It serves as a reference point for understanding how doping influences the energy levels. When dopants are introduced, the relative position of the Fermi level with respect to the intrinsic level indicates whether the material is n-type or p-type, and it plays a central role in determining the electrical behavior of semiconductors.

Built-In Potential

The built-in potential of a p-n junction is the voltage created by the diffusion of carriers across the junction, resulting in an electric field that opposes further diffusion. It can be determined from the difference between the Fermi levels on the p and n sides at equilibrium. This potential is crucial for the operation of devices like diodes and is computed by taking into account the relative positions of the conduction and valence bands along with the doping concentrations.
