An ac series circuit has an impedance of 192 Ω, and the phase angle between the current and the

step 1 In the given problem, impedance of the AC circuit is given as Z is equal to 192 om. The phase di

An ac series circuit has an impedance of 192 Ω, and the...

An ac series circuit has an impedance of $192 \Omega,$ and the phase angle between the current and the voltage of the generator is $\phi=-75^{\circ} .$ The circuit contains a resistor and either a capacitor or an inductor. Find the resistance $R$ and the capacitive reactance $X_{\mathrm{C}}$ or the inductive reactance $X_{\mathrm{L}}$ whichever is appropriate.

Key Concepts

Impedance in AC Circuits

Impedance is the overall opposition to alternating current, combining both resistance (real part) and reactance (imaginary part). It is typically represented as a complex number, where its magnitude indicates the total opposition to current, and its phase angle shows the phase shift between the voltage and current waveforms.

Phase Angle in AC Circuits

The phase angle is the measure of the lead or lag between the voltage and current in an AC circuit. A negative phase angle indicates that the current is leading the voltage, which is commonly associated with capacitive behavior, while a positive phase angle suggests that the current lags the voltage, indicating inductive behavior.

Resistive and Reactive Components

AC circuits are composed of resistive elements, which dissipate energy, and reactive elements, which store and return energy to the circuit. The resistive part, represented by a pure resistance, does not change with frequency, whereas the reactive part, whether it is due to capacitance or inductance, depends on the frequency and contributes an imaginary component to the impedance.

AC Circuit Analysis Techniques

Analyzing an AC circuit involves decomposing the measured impedance into its resistive and reactive components using trigonometric relationships. This method leverages the magnitude of the impedance and the phase angle to calculate individual values of resistance and reactance, which in turn helps to determine whether the reactive component is capacitive (if the phase angle is negative) or inductive (if the phase angle is positive).
