An accelerometer is constructed by suspending a mass of 0.1 kg from a spring of stiffness 10,00

step 1 In this problem first I will just write the given data here. The value of m is given as 0 .1 KG

An accelerometer is constructed by suspending a mass of 0.1...

An accelerometer is constructed by suspending a mass of $0.1 \mathrm{~kg}$ from a spring of stiffness $10,000 \mathrm{~N} / \mathrm{m}$ with negligible damping. When mounted on the foundation of an engine, the peak-to-peak travel of the mass of the accelerometer has been found to be $10 \mathrm{~mm}$ at an engine speed of $1000 \mathrm{rpm}$. Determine the maximum displacement, maximum velocity, and maximum acceleration of the foundation.

Key Concepts

Simple Harmonic Motion

This concept deals with motion where the restoring force is proportional to the displacement and acts in the opposite direction. In systems that exhibit simple harmonic motion, such as a mass attached to a spring, the displacement, velocity, and acceleration follow sinusoidal forms, and their maximum values occur at specific phase angles. Understanding SHM allows one to derive relationships between these quantities and predict system behavior over time.

Mass-Spring System Dynamics

A mass–spring system is a primary model in dynamics that illustrates the principles of oscillatory motion. In such a system, the mass is subject to a restoring force provided by the spring, as described by Hooke’s law. The interplay between the inertial forces of the mass and the elastic restoring force of the spring determines how the system responds to disturbances, such as base excitations or external forces.

Natural Frequency

The natural frequency is a fundamental property of a mass-spring system that defines the rate at which the system oscillates in the absence of external forcing or damping. It is determined by the mass and the stiffness of the spring, typically expressed as the square root of the ratio of the spring constant to the mass. Knowing the natural frequency is important for understanding resonance and for designing systems sensitive to acceleration measurements.

Frequency Conversion

In dynamics problems, it is often necessary to convert rotational speeds, such as RPM (revolutions per minute), into standard frequency measures like Hertz or angular frequency in radians per second. This conversion is essential for ensuring that the periodic functions used to describe displacement, velocity, and acceleration are correctly formulated in consistent units.

Amplitude and Peak-to-Peak Relation

Understanding the relationship between amplitude and peak-to-peak displacement is key when interpreting measurements from oscillatory systems. The amplitude is defined as the maximum displacement from the equilibrium position, while the peak-to-peak value represents the total distance between the highest and lowest points of the oscillation. This conversion is important for accurately characterizing the system's response and extracting dynamic parameters.
