An air flow at 90 psia, 1100 R, M=0.3 flows into a convergent-divergent nozzle with M=1 at the t

step 1 The air flow at a 90 PSI. So we can write the inlet pressure that is 90 PSI. The inlet temperatu

An air flow at 90 psia, 1100 R, M=0.3 flows into a...

An air flow at 90 psia, $1100 \mathrm{R}, M=0.3$ flows into a convergent-divergent nozzle with $M=1$ at the throat. Assume a reversible flow with an exit area twice the throat area and find the exit pressure and temperature for subsonic exit flow to exist.

Key Concepts

Stagnation Properties

Stagnation properties, such as stagnation (total) pressure and temperature, are the conditions a fluid would attain if it were decelerated isentropically to zero velocity. These properties remain constant along an isentropic flow and serve as reference conditions for relating the actual static flow properties at various Mach numbers. They are pivotal in computations involving compressible flow, particularly in nozzles, to ensure the consistency of energy and mass conservation.

Area-Mach Number Relationship

This relationship is derived from the continuity equation and the isentropic flow equations, linking the flow area with the Mach number at a given station in the nozzle. It explains how changes in the cross-sectional area of the nozzle can accelerate or decelerate the flow, and it defines the unique behavior of sonic conditions at the throat. The relationship is essential for determining the necessary areas at different points to achieve specific Mach numbers.

Isentropic Flow

This concept refers to a flow process that is both adiabatic (no heat transfer) and reversible. In compressible flow problems, isentropic relations provide a consistent way to relate pressure, temperature, density, and Mach number between different points in the nozzle. These relationships are critical for determining how a fluid’s static and stagnation properties change as it flows through areas of varying cross-section.

Mach Number

Mach number is defined as the ratio of the fluid velocity to the local speed of sound. It is a key parameter in compressible flow, as it determines whether the flow is subsonic, sonic, or supersonic. The given problem uses specific Mach numbers to set conditions at the inlet, throat, and exit of the nozzle, which in turn affect the static pressure and temperature distributions.

Convergent-Divergent Nozzles

A convergent-divergent nozzle, also known as a de Laval nozzle, is used to accelerate a compressible fluid to supersonic speeds. The nozzle design includes a converging section that accelerates the fluid to Mach 1 at the throat (choking condition) and a diverging section that further accelerates or decelerates the flow depending on the back pressure conditions. The nozzle geometry thus plays a vital role in controlling the flow regime and ensuring the desired Mach number distribution.
