An air-standard Diesel cycle has a compression ratio of 18.2...

An air-standard Diesel cycle has a compression ratio of $18.2 .$ Air is at $120^{\circ} \mathrm{F}$ and 14.7 psia at the beginning of the compression process and at $3200 \mathrm{R}$ at the end of the heataddition process. Accounting for the variation of specific heats with temperature, determine $(a)$ the cutoff ratio, $(b)$ the heat rejection per unit mass, and $(c)$ the thermal efficiency.

Key Concepts

Heat Rejection

Heat rejection refers to the energy removed from the working fluid during the cooling process in a thermodynamic cycle. In the Diesel cycle, after the expansion process, the remaining energy is expelled to return the system to its initial state. This rejected heat directly affects the net work output and overall cycle efficiency.

Thermal Efficiency

Thermal efficiency is a measure of how well a thermodynamic cycle converts the heat input into useful work output. For the Diesel cycle, it depends on factors such as compression ratio, cutoff ratio, and the specific heat values. Calculating the thermal efficiency provides insights into the performance of the cycle and helps in comparing different engine designs or operating conditions.

Cutoff Ratio

The cutoff ratio in a Diesel cycle is the ratio of the volume at the end of the heat addition process to the volume at the beginning of the heat addition process. It defines the point at which fuel injection stops and directly impacts the amount of fuel that is burned, the work produced during expansion, and consequently the overall efficiency of the cycle.

Specific Heats Variation

In real gases, the specific heats (cp and cv) vary with temperature, affecting the energy transfer calculations during compression, heat addition, and expansion processes. Accounting for these variations is critical for accurate analysis of cycles, as it influences the amount of heat required to achieve a certain temperature change and, in turn, the efficiency and work outputs.

Compression Ratio

The compression ratio is a fundamental parameter in engine cycles, defined as the ratio of the maximum to minimum volume in the combustion chamber. It significantly influences the thermal efficiency and power output of the engine, as a higher compression ratio generally leads to improved efficiency by increasing the pressure and temperature at the end of the compression stroke.

Air?Standard Assumption

The air?standard assumption simplifies real engine processes by modeling the working fluid as air undergoing ideal gas behavior, with all processes considered internally reversible. This assumption allows the use of constant properties (or their variations) and simplified equations to analyze the cycle, abstracting complex combustion phenomena.

Diesel Cycle

The Diesel cycle is an idealized thermodynamic cycle that describes the functioning of a compression ignition engine. It is characterized by a high compression process, constant-pressure heat addition, and constant-volume heat rejection, representing the combustion process in diesel engines. This cycle is used for theoretical analysis to understand engine efficiency and work output under various operating conditions.

Transcript

00:01 We have given with the question that an air standard diesel cycle has a compression ratio of 18 .2.

00:05 Air is at 120 degree fahrenheit and 14 .7 pisa at the beginning of the compression process and at 3 ,200 hour at the end of the creation process.

00:14 Accounting for the variation of specific heats with temperature, determine the cutoff ratio, the heat rejection per unit mass and the thermal efficiency.

00:23 So in this question, we have to find the cutoff ratio.

00:30 That is rc.

00:32 And b, the heat rejection per unit mass.

00:40 That is heat rejection per unit mass.

00:52 C, the thermal efficiency.

00:56 These three things you have to find.

01:01 So to solve this, we have given with the compression ratio, r is equal to 18 .2.

01:14 And the pv diagram is like this.

01:28 This is 4, 1, 2 and 3.

01:32 This is the heat input and this is the heat output.

01:41 So during process 1 to 2, that is is is is is is is encirropic compression.

01:56 T1 is 580r, that is u1, vr 1, this is u1 at temperature t1, is equal to 98 .90.

02:21 British thermal unit vr1 is equals to 120 .70 and now vr2 is equal to v2 over v1 into vr1 it is equals to 1 over rr1 that is equals to 1 over 18 .2 into 120 .70 which is equals to 6 .663 to add temperature d2 and h2 is equals to 1725 .r and h2 is 429 .56...
