An ammeter with a full-scale deflection for $I=10.0 \mathrm{A}$ has an internal resistance of $24 \Omega .$ We need to use this ammeter to measure currents up to 12.0 A. The lab instructor advises that we get a resistor and use it to protect the ammeter. (a) What size resistor do we need and how should it be connected to the ammeter, in series or in parallel? (b) How do we interpret the ammeter readings?

An ammeter with a full-scale deflection for $I=10.0 \mathrm{A}$ has an internal resistance of $24 \Omega .$ We need to use this
ammeter to measure currents up to 12.0 A. The lab instructor advises that we get a resistor and use it to protect the ammeter. (a) What size resistor do we need and how should it be connected to the ammeter, in series or in parallel? (b) How do we interpret the ammeter readings?

Key Concepts

Ammeter Operation

An ammeter is designed to measure the electric current flowing through a circuit. It typically offers a full-scale deflection current value, meaning that above this rated current, the device can be damaged unless circuit modifications are made.

Internal Resistance

The internal resistance of an ammeter is the inherent resistance within the device that contributes to a voltage drop when current flows through it. This resistance is crucial because it influences both the accuracy of the measurement and the behavior of the ammeter when used within a circuit.

Shunt Resistor and Parallel Connection

A shunt resistor is an auxiliary resistor used to extend the measurement range of an ammeter by safely bypassing excess current. When connected in parallel to the ammeter, it diverts part of the total current, ensuring that the current through the ammeter does not exceed its maximum rating.

Extended Measurement Range Technique

Extending the measurement range of an instrument involves altering the circuit configuration so that the device measures only a fraction of the total current. This is achieved by calculating the correct value for a shunt resistor in parallel with the ammeter, effectively protecting the instrument while allowing accurate total current calculation.

Interpretation of Readings

When a shunt resistor is employed, the ammeter reading corresponds to only the current flowing through it, not the total current passing through the circuit. To ascertain the actual current, one must apply current division principles, taking into account the ratio of the shunt resistor to the internal resistance of the ammeter.
