An anisotropic material has coefficients of linear thermal expansion $\alpha_{1}, \alpha_{2}$ and $\alpha_{3}$ along $x, y$ and $z$ -axis respectively. Coefficient of cubical expansion of its material will be equal to (a) $\alpha_{1}+\alpha_{2}+\alpha_{3}$ (b) $\alpha_{1}+2 \alpha_{2}+3 \alpha_{3}$ (c) $3 \alpha_{1}+2 \alpha_{2}+\alpha_{3}$ (d) $\frac{\alpha_{1}+\alpha_{2}+\alpha_{3}}{3}$

An anisotropic material has coefficients of linear thermal expansion $\alpha_{1}, \alpha_{2}$ and $\alpha_{3}$ along $x, y$ and $z$ -axis respectively. Coefficient of cubical expansion of its material will be equal to
(a) $\alpha_{1}+\alpha_{2}+\alpha_{3}$
(b) $\alpha_{1}+2 \alpha_{2}+3 \alpha_{3}$
(c) $3 \alpha_{1}+2 \alpha_{2}+\alpha_{3}$
(d) $\frac{\alpha_{1}+\alpha_{2}+\alpha_{3}}{3}$

Key Concepts

Anisotropic Materials

Anisotropic materials are those whose physical properties, including thermal expansion, vary with direction. This means that the response of the material to temperature change can be different along each principal axis, requiring separate coefficients of thermal expansion for each axis.

Coefficient of Linear Thermal Expansion

The coefficient of linear thermal expansion is a measure of the rate at which a material's length changes per unit temperature change along a specific direction. In anisotropic materials, different coefficients (?1, ?2, and ?3) are used to describe expansion along the x, y, and z axes respectively.

Coefficient of Cubical Thermal Expansion

The coefficient of cubical thermal expansion represents the rate at which the volume of a material changes per unit temperature change. For small temperature variations, the overall volumetric expansion can be approximated as the sum of the individual linear expansions along each orthogonal axis, which in the anisotropic case is ?1 + ?2 + ?3.

Small Strain Approximation

The small strain approximation is an assumption used when the changes in dimensions due to temperature are very small. This approximation allows for linearization of the expansion equations, meaning that the volumetric expansion can be approximated by just the sum of the linear terms without needing to account for higher-order effects.
