An automobile is modeled as a single-degree-of-freedom system vibrating in the vertical direction. It is driven along a road whose elevation varies sinusoidally. The distance from peak to trough is $0.2 \mathrm{~m}$ and the distance along the road between the peaks is $35 \mathrm{~m}$. If the natural frequency of the automobile is $2 \mathrm{~Hz}$ and the damping ratio of the shock absorbers is 0.15, determine the amplitude of vibration of the automobile at a speed of $60 \mathrm{~km} /$ hour. If the speed of the automobile is varied, find the most unfavorable speed for the passengers.

Key Concepts

Road Profile Excitation

Road profile excitation involves the variations in road surface elevation that act as a forcing function on the vehicle. Sinusoidal or periodic variations in the road profile convert into external forces when a vehicle travels over them. Understanding the characteristics of this excitation is important for predicting vehicle vibration levels and for designing suspension systems that effectively isolate passengers from road irregularities.

Single Degree of Freedom (SDOF) System

A single degree of freedom system is a simplified dynamic model consisting of one mass, one spring, and, optionally, one damper. It is used to represent systems whose response can be characterized by a single coordinate, such as vertical vibrations of an automobile. This model aids in understanding the system's response to external forces by analyzing how the mass moves relative to its equilibrium position.

Natural Frequency

The natural frequency of a system is the frequency at which it tends to oscillate in the absence of damping and external forces. It is a fundamental property determined by the system's stiffness and mass. In vibration analysis, knowing the natural frequency is crucial because it indicates the rate at which the system will vibrate under its inherent dynamic conditions.

Damping Ratio

The damping ratio is a dimensionless parameter that quantifies the level of energy dissipation in a system relative to critical damping. It determines how quickly oscillations decay following a disturbance. A damping ratio of 0.15 indicates that the system experiences moderate damping, which affects both the amplitude of the response and the system’s tendency to sustain oscillations when exposed to periodic forcing.

Forced Vibration

Forced vibration refers to the response of a system when it is subjected to an external, time-varying force. In such cases, the system’s response depends on the frequency and amplitude of the forcing function as well as the inherent properties of the system, including its natural frequency and damping. Analyzing forced vibration is essential for predicting how the system will behave under realistic operating conditions.

Resonance

Resonance occurs when the frequency of the external force matches or is close to the natural frequency of the system, leading to a significant increase in the amplitude of vibration. This phenomenon is critical in design and analysis because sustained resonance can cause excessive vibrations, leading to discomfort or even structural damage. Identifying potential resonance conditions helps in mitigating adverse effects in engineering applications.

Speed-Dependent Forcing Frequency

The forcing frequency experienced by a moving vehicle over a periodic road profile is dependent on the vehicle's speed. This concept involves converting the spatial periodicity of the road into a temporal frequency as the vehicle travels. It is critical in determining how the external excitation interacts with the vehicle's natural dynamics, thereby affecting the amplitude of the response and identifying the speeds at which discomfort or resonance is most likely to occur.
