An ethylene glycol-distilled water mixture with a mass fraction of $0.72$ and a flow rate of $2.05 \times 10^{-4} \mathrm{~m}^{3} / \mathrm{s}$ flows inside a tube with an inside diameter of $0.0158 \mathrm{~m}$ and a uniform wall heat flux boundary condition. For this flow, determine the Nusselt number at the location $x / D=10$ for the inlet tube configuration of $(a)$ bell-mouth and $(b)$ re-entrant. Compare the results for parts $(a)$ and $(b)$. Assume the Grashof number is $\mathrm{Gr}=60,000$. The physical properties of an ethylene glycoldistilled water mixture are $\operatorname{Pr}=33.46, \nu=3.45 \times 10^{-6} \mathrm{~m}^{2} / \mathrm{s}$, and $\mu_{b} / \mu_{s}=2.0$.

Key Concepts

Nusselt Number

The Nusselt number is a dimensionless parameter that characterizes the convective heat transfer relative to conductive heat transfer across a fluid layer. It is fundamental in determining the heat transfer rate from a surface to a fluid, and its evaluation is key in understanding the efficiency of heat removal or addition in a flowing system such as a tube.

Forced Convection in Pipes

In forced convection, the movement of the fluid is primarily driven by external means such as a pump, rather than buoyancy effects. Heat transfer in pipes under forced convection conditions is dictated by the flow characteristics and the interaction between the fluid and the heated or cooled surface, making it essential to analyze parameters like flow rate, velocity profiles, and the development of thermal boundaries.

Entrance Region Development

The entrance or developing region of a tube is where the flow and thermal boundary layers are still evolving from the inlet conditions until they reach a fully developed state. The characteristics of heat transfer in this region differ significantly from the fully developed region, and understanding it is crucial when evaluating local heat transfer coefficients, such as those represented by the Nusselt number at specific axial positions.

Inlet Geometry Effects

The design of the tube inlet, such as bell-mouth or re-entrant configurations, plays an important role in how the fluid flow enters the tube and develops downstream. These geometric differences can significantly affect the initial velocity profile and the subsequent thermal development of the flow, thereby influencing the local heat transfer coefficients and the resulting Nusselt number.

Dimensionless Numbers in Heat Transfer

Dimensionless numbers like the Grashof and Prandtl numbers are central to the study of convective heat transfer as they encapsulate the effects of buoyancy, viscous forces, and thermal diffusivity. The Grashof number, in particular, relates buoyancy to viscous forces, while the Prandtl number compares momentum diffusivity to thermal diffusivity; together, they help predict the heat transfer behavior in both forced and mixed convection regimes.

Fluid Thermophysical Properties

Understanding the thermophysical properties of the fluid, such as viscosity, thermal conductivity, and specific heat, is essential in analyzing convective heat transfer. These properties, often combined into dimensionless numbers like the Prandtl number, determine how effectively the fluid can transport heat through conduction and convection, thereby influencing design and performance calculations in thermal systems.
