An ideal-gas mixture of helium and argon gases with...

An ideal-gas mixture of helium and argon gases with identical mass fractions enters a turbine at $1500 \mathrm{K}$ and $1 \mathrm{MPa}$ at a rate of $0.12 \mathrm{kg} / \mathrm{s},$ and expands isentropically to $100 \mathrm{kPa} .$ The power output of the turbine is (a) $253 \mathrm{kW}$ (b) $310 \mathrm{kW}$ (c) $341 \mathrm{kW}$ (d) $463 \mathrm{kW}$ (e) $550 \mathrm{kW}$

An ideal-gas mixture of helium and argon gases with identical mass fractions enters a turbine at $1500 \mathrm{K}$ and $1 \mathrm{MPa}$ at a rate of $0.12 \mathrm{kg} / \mathrm{s},$ and expands isentropically to $100 \mathrm{kPa} .$ The power output of the turbine is
(a) $253 \mathrm{kW}$
(b) $310 \mathrm{kW}$
(c) $341 \mathrm{kW}$
(d) $463 \mathrm{kW}$
(e) $550 \mathrm{kW}$

Key Concepts

Isentropic Process

An isentropic process is one in which the entropy of the system remains constant. This is typically an idealization in thermodynamics representing a reversible adiabatic process where no heat is exchanged with the surroundings. In practical applications, such as turbine expansion, assuming an isentropic process simplifies the analysis and allows for the use of compressible flow relations to relate inlet and outlet states, such as temperature, pressure, and specific volume.

Ideal Gas Mixture Properties

Ideal gas mixtures are treated using the ideal gas law, which relates pressure, volume, and temperature. When dealing with mixtures, properties such as the specific gas constant and heat capacities are determined based on the contributions of each component, often using weighted averages with respect to mass or moles. This is essential when assessing the performance of processes such as turbine expansions, as the overall behaviour of the gas mixture is influenced by the properties of each individual gas.

Turbine Energy Balance

The turbine energy balance involves the conservation of energy applied to the flow through the turbine, where the work output is derived from the change in enthalpy of the working fluid. In an ideal (isentropic) expansion, the enthalpy drop is directly related to the temperature drop, and when multiplied by the mass flow rate, it yields the power produced by the turbine. This concept is pivotal in thermodynamics and energy conversion systems.

Mass Flow Rate in Turbine Calculations

Mass flow rate is a measure of the mass of fluid passing through a section per unit time and is crucial in determining the total energy transfer in systems like turbines. In energy balances, the mass flow rate is multiplied by the specific energy change (such as the enthalpy drop) to calculate the total power output. This concept links the microscopic properties of the fluid to the macroscopic energy systems performance.

Transcript

00:01 110 in our textbook has to deal with output of energy and it states that an ideal gas mixture of helium and argon, each with identical mass fractions, enters a turbine at this specific temperature and pressure shown here, p1, at a rate here, give a mass rate of 0 .12 kilograms per second.

00:20 It then expands isentropically to 100 kilopascals, or here for p2, i put 0 .1 megapascals to have the same units of pressure.

00:29 We want to find the power output of this turbine.

00:35 So in order to do that, we can use a relationship that the power output as a unit of energy is equivalent to the work output per unit mass times the mass rate.

00:50 I'm sorry, oh, sorry, this is out.

00:53 This is odd.

00:55 Sorry about that.

00:59 So leaving our mass rate out in front, we can find that this output per unit mass and our textbook is given by the relationship of change in enthopies.

01:15 And we can expand that second term, sorry, to the following.

01:25 So here we're given initial temperature.

01:26 We're not given t2, but in the question, again, it did state that we are, that the mixture is expanding isotropically, isentropically.

01:39 So we do have an expression that you can use for this second temperature, and we will use sentence for that.

01:45 So if i expand this out slightly, so i can take this mass rate, which is constant throughout, t1, which is constant throughout, i need to deal with, first of all, the ratio of each gas in terms of its specific heat.

02:10 And since i didn't write it down, but it does state in the question that they're equal amounts of each, you take the mass fraction of each, multiplied by this specific heat for each gas.

02:21 So this is, say, first term for helium, and the same for argon...
