An object $O O^{\prime}, 9.0 \mathrm{~cm}$ high, is $27 \mathrm{~cm}$ in front of a thin concave lens of focal length $-18 \mathrm{~cm}$. Determine the position and height of its image $I I^{\prime}(a)$ by construction and $(b)$ by computation. (a) Choose the two convenient rays from $O$ shown in Fig. $38-6$. (1) A ray $O P$, parallel to the optical axis, is refracted outward in the direction $D$ as if it came from the principal focus $F$. (2) A ray through the optical center of the lens is drawn as a straight line $O C$. Then $I I^{\prime}$ is the image of $O O^{\prime}$. Images formed by concave or divergent lenses are virtual, erect, and smaller. (b) $\frac{1}{s_{o}}+\frac{1}{s_{i}}=\frac{1}{f}$ or $\frac{1}{27 \mathrm{~cm}}+\frac{1}{s_{i}}=-\frac{1}{18 \mathrm{~cm}} \quad$ or $\quad s_{i}=-10.8 \mathrm{~cm}=-11 \mathrm{~cm}$ Since $s_{i}$ is negative, the image is virtual, and it is $11 \mathrm{~cm}$ in front of the lens. $M_{T}=\frac{y_{i}}{y_{o}}=-\frac{s_{i}}{s_{o}}=-\frac{-10.8 \mathrm{~cm}}{27 \mathrm{~cm}}=0.40 \quad$ and so $\quad y_{i}=y_{o} M_{T}=(0.40)(9.0 \mathrm{~cm})=3.6 \mathrm{~cm}$ When $M_{T}>0$, the image is upright, and the same conclusion follows from the fact that $y_{i}>0 .$

An object $O O^{\prime}, 9.0 \mathrm{~cm}$ high, is $27 \mathrm{~cm}$ in front of a thin concave lens of focal length $-18 \mathrm{~cm}$. Determine the position and height of its image $I I^{\prime}(a)$ by construction and $(b)$ by computation.
(a) Choose the two convenient rays from $O$ shown in Fig. $38-6$.
(1) A ray $O P$, parallel to the optical axis, is refracted outward in the direction $D$ as if it came from the principal focus $F$.
(2) A ray through the optical center of the lens is drawn as a straight line $O C$.
Then $I I^{\prime}$ is the image of $O O^{\prime}$. Images formed by concave or divergent lenses are virtual, erect, and smaller.
(b) $\frac{1}{s_{o}}+\frac{1}{s_{i}}=\frac{1}{f}$ or
$\frac{1}{27 \mathrm{~cm}}+\frac{1}{s_{i}}=-\frac{1}{18 \mathrm{~cm}} \quad$ or $\quad s_{i}=-10.8 \mathrm{~cm}=-11 \mathrm{~cm}$
Since $s_{i}$ is negative, the image is virtual, and it is $11 \mathrm{~cm}$ in front of the lens.
$M_{T}=\frac{y_{i}}{y_{o}}=-\frac{s_{i}}{s_{o}}=-\frac{-10.8 \mathrm{~cm}}{27 \mathrm{~cm}}=0.40 \quad$ and so $\quad y_{i}=y_{o} M_{T}=(0.40)(9.0 \mathrm{~cm})=3.6 \mathrm{~cm}$
When $M_{T}>0$, the image is upright, and the same conclusion follows from the fact that $y_{i}>0 .$

Key Concepts

Thin Lens Equation

The thin lens equation, 1/s? + 1/s? = 1/f, is a fundamental relation in geometric optics that connects the object distance (s?), the image distance (s?), and the focal length (f) of a lens. It allows us to calculate the position of the image for any given object placement relative to a thin lens.

Virtual Image Formation

Virtual images are formed when the diverging rays of light, after passing through a lens, appear to originate from a point behind the lens. Unlike real images, the light does not actually converge at the image location, making it impossible to project on a screen, and virtual images are typically upright.

Magnification

Magnification in lens systems describes the ratio of the image height to the object height and can also be expressed in terms of the distances of the object and image from the lens. It indicates how the size of the image compares to the object, with the sign of the magnification telling us whether the image is inverted or upright.

Ray Diagrams

Ray diagrams are graphical methods used in optics to determine the position and characteristics of images formed by lenses. By tracing specific rays, such as those parallel to the optical axis or through the optical center, one can accurately construct the location, orientation, and size of the image.

Principal Focus

The principal focus (or focal point) of a lens is the point at which parallel rays of light either converge (in converging lenses) or appear to diverge from (in diverging lenses) after passing through the lens. It plays a critical role in defining the focal length and the overall behavior of the lens in imaging applications.

Optical Center Behavior

The optical center of a lens is the point on the lens through which light rays pass without deviation. This property simplifies image construction since a ray drawn through the optical center will continue in a straight line, aiding in the determination of the image location in ray diagrams.
