An RLC circuit is used in a radio to tune into an FM station broadcasting at f 5 99.7 MHz. The resistance in the circuit is $R=12.0 \Omega,$ and the inductance is $L=1.40 \mu \mathrm{H}$ . What capacitance should be used?

Key Concepts

RLC Circuit

An RLC circuit is an electrical network composed of a resistor, an inductor, and a capacitor. The interplay between the energy dissipation in the resistor and energy storage in both the inductor and capacitor gives rise to a wide range of dynamic behaviors, including oscillations and resonance.

Resonance in RLC Circuits

Resonance in an RLC circuit occurs when the inductive reactance equals the capacitive reactance, allowing the circuit to oscillate at a particular frequency with minimal impedance. At this frequency, known as the resonant frequency, the circuit can efficiently transfer energy between the inductor and the capacitor.

Resonant Frequency Calculation

The resonant frequency of an RLC circuit is calculated using the formula ?? = 1/?(LC), where ?? is the angular frequency. Converting to standard frequency using f? = ??/(2?) shows how the values of the inductance and capacitance determine the oscillation frequency of the circuit.

Capacitance Determination

Once the desired resonant frequency is specified, the capacitance needed in the circuit can be determined by rearranging the resonant frequency formula to solve for C. This process involves manipulating the equation to isolate the capacitance, emphasizing the relationship between frequency, inductance, and capacitance.

Unit Conversion

Accurate calculations in circuit analysis require consistency in units. Converting quantities such as frequency or inductance to the appropriate SI units is essential when applying formulas, ensuring that the resulting values for components like capacitance are correct.
