As a group, create a single schematic drawing of a factory...

As a group, create a single schematic drawing of a factory that uses the Haber-Bosch process and the Ostwald process to make $\mathrm{NH}_{4} \mathrm{NO}_{3}$ fertilizer. The factory may only take in $\mathrm{N}_{2}(g), \mathrm{H}_{2}(g)$ and $\mathrm{O}_{2}(g) .$ Pass your diagram around the group and have each group member add one step in the process. Where might the factory obtain $\mathrm{H}_{2} ?$

Key Concepts

Haber-Bosch Process

The Haber-Bosch process is an industrial method for synthesizing ammonia by combining atmospheric nitrogen (N?) with hydrogen gas (H?) under high pressure and temperature in the presence of an iron-based catalyst. This process revolutionized agricultural chemistry by providing a reliable method of ammonia production, which is a critical precursor for many fertilizers and chemicals.

Ostwald Process

The Ostwald process is an industrial procedure used to convert ammonia into nitric acid through catalytic oxidation of ammonia in the presence of oxygen. The nitric acid produced is then typically combined with ammonia to produce ammonium nitrate, an important fertilizer. This process efficiently transforms a single reactant into a useful intermediate by exploiting controlled oxidation reactions.

Ammonium Nitrate Fertilizer Synthesis

Ammonium nitrate fertilizer is produced by reacting ammonia with nitric acid, which are derived respectively from the Haber-Bosch and Ostwald processes. This synthesis is crucial in providing high-nitrogen fertilizers that significantly boost crop yields, making the understanding of these underlying chemical processes essential in industrial chemistry and agricultural applications.

Hydrogen Production

Hydrogen production is a key aspect of industrial chemistry, as hydrogen is a reactant in processes like the Haber-Bosch synthesis of ammonia. Hydrogen can be generated via methods such as water electrolysis or steam reforming of hydrocarbons. In contexts where only specific gases are allowed as inputs, industries must strategically manage and possibly recycle byproducts to ensure a steady supply of hydrogen for continuous operation.
