Assume that the bicycle in the figure is moving forward at a...

Assume that the bicycle in the figure is moving forward at a constant rate. Point $A$ is on the edge of the 30 -inch rear tire, and point $B$ is on the edge of the 20 -inch front tire. (IMAGE CAN'T COPY). a. Which point $(A \text { or } B)$ has the greater angular velocity? Explain. $B$ b. Which point $(A \text { or } B)$ has the greater linear velocity? Explain. Both points have the same linear velocity.

Assume that the bicycle in the figure is moving forward at a constant rate. Point $A$ is on the edge of the 30 -inch rear tire, and point $B$ is on the edge of the 20 -inch front tire.
(IMAGE CAN'T COPY).
a. Which point $(A \text { or } B)$ has the greater angular velocity? Explain. $B$
b. Which point $(A \text { or } B)$ has the greater linear velocity? Explain. Both points have the same linear velocity.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Rolling Motion

Rolling motion involves an object rotating while simultaneously translating along a surface. In the case of a wheel, this means that as it rotates, a point on its edge comes in contact with the ground and momentarily has zero relative velocity, ensuring no slipping occurs. This concept is crucial for understanding how both the front and rear wheels of a moving bicycle work together under uniform motion.

Angular Velocity

Angular velocity measures the rate at which an object rotates, defined as the change in angular displacement over time. When two wheels are moving linearly at the same speed, the wheel with the smaller radius will have a higher angular velocity because angular velocity is inversely proportional to the radius (? = v/r). This concept explains why, in a bicycle, the smaller front wheel rotates faster in terms of radians per second than the larger rear wheel.

Linear Velocity

Linear velocity describes the speed at which an object moves along a straight path. For rolling objects without slipping, every point on the wheel's rim, as well as the center of mass, moves with the same linear velocity as the frame of the bicycle. This uniform linear motion ensures that, regardless of the angular velocity differences due to varying radii, the bicycle maintains a constant forward speed.
