Assume that the Flettner rotor ship of Fig. P8.54 has a...

Assume that the Flettner rotor ship of Fig. P8.54 has a water resistance coefficient of $0.005 .$ How fast will the ship sail in seawater at $20^{\circ} \mathrm{C}$ in a 20 -ft/s wind if the keel aligns itself with the resultant force on the rotors? [Hint: This is a problem in relative velocities.]

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Force Equilibrium

Force equilibrium occurs when all forces acting on an object balance each other, resulting in steady motion without acceleration. In maritime dynamics, the ship reaches a steady sailing speed when the aerodynamic thrust from the rotors equals the hydrodynamic drag from the water, with the keel aligning itself with the resultant force.

Fluid Drag

Fluid drag is the resistance force that an object experiences as it moves through a fluid, such as water. The water resistance coefficient quantifies this drag force in relation to the ship’s speed and is used to balance the forces from the wind against the hydrodynamic drag to determine the ship's steady speed.

Magnus Effect

The Magnus effect refers to the lift force generated by a spinning object moving through a fluid. It is central to the operation of the Flettner rotor ship, where the rotation of the cylinders creates a force perpendicular to the wind direction, contributing to the ship’s propulsion.

Relative Velocity

This concept involves the difference in speed between two moving entities—in this case, between the wind and the ship. The effective wind force acting on the Flettner rotor is determined by the wind speed as experienced by the moving ship rather than the speed relative to a static observer.
