Auto mechanics use the following formula to calculate the...

Auto mechanics use the following formula to calculate the horsepower (HP) of a car engine: $\mathrm{HP}=$ Torque $\cdot \mathrm{RPM} / \mathrm{C}$ In this expression, Torque is the torque produced by the engine in $f_{t} \cdot \| b, R P M$ is the angular speed of the engine in revolutions per minute, and $C$ is a dimensionless constant. (a) Find the numerical value of $C$. (b) The Shelby Series 1 engine is advertised to generate 320 hp at 6500 rpm. What is the corresponding torque produced by this engine? Give your answer in $f t \cdot$ lb.

Key Concepts

Unit Conversion and Dimensional Analysis

Unit conversion and dimensional analysis are essential techniques used to reconcile differing measurement systems in engine performance formulas. They ensure that the combination of torque and rotational speed yields a power output in horsepower. The constant in the horsepower calculation formula arises from converting units, such as turning revolutions per minute and foot-pounds into a power standard (horsepower), and confirms the consistency and validity of the derived formula.

Horsepower

Horsepower is a unit of power that quantifies the rate at which work is performed. In automotive contexts, it is used to describe the performance capacity of an engine, linking the engine’s torque output and its rotational speed. One horsepower is historically defined as the ability to do 550 foot-pounds of work per second. This measure provides a standard way to compare engine performance across different vehicles.

Torque

Torque is a measure of the rotational force produced by an engine. It represents how much force is acting to rotate an object around an axis, and is commonly measured in units such as foot-pounds (ft·lb) in the context of automotive mechanics. Understanding torque is crucial because it determines the engine’s ability to do work at a rotational level, influencing acceleration and overall vehicle performance.

Angular Velocity (RPM)

Angular velocity, measured in revolutions per minute (RPM), indicates how quickly the engine’s crankshaft is rotating. It is a key factor in the relationship between torque and power because even if an engine produces a high amount of torque, the engine must also spin at a high speed to produce significant power. RPM serves as a direct measure of how fast the work is being done by the engine.
