Bar A B is free at its end A and fixed at its base B. Determine the allowable centric load 𝐏 if

step 1 Let us first calculate the area of the cross section. So it will be area is equal to length mult

Bar A B is free at its end A and fixed at its base B....

Key Concepts

Aluminum Alloy Mechanical Properties

Different aluminum alloys, such as 6061-T6 and 2014-T6, have distinct mechanical properties, including yield strength and elastic modulus. These properties determine how the material responds under load—both in terms of elastic deformation and the onset of yielding. When determining the allowable centric load, it’s important to consider these properties because they directly affect the maximum stress the material can sustain without failing.

Euler's Critical Load

This concept describes the load at which a slender column or bar becomes unstable and buckles under compressive forces. The Euler formula relates the critical load to the material's elastic modulus, the moment of inertia of the cross?section, the effective length of the column, and a constant that depends on the end conditions. For a cantilever (fixed at one end and free at the other), the effective length is different from that of a column with both ends pinned, making it a key factor in calculating the allowable load.

Boundary Conditions in Buckling

In stability and buckling analysis, the way a column or bar is supported (its boundary conditions) has a significant influence on the critical load. A cantilever, being fixed at one end and free at the other, has a higher effective length factor, which lowers the critical buckling load compared to columns with more constrained supports. This concept is essential to accurately determine the load-carrying capacity in compression.
