Blue and yellow streams of paint at $60^{\circ} \mathrm{F}$ (each with a density of 1.6 slugs/ft $^{3}$ and a viscosity 1000 times greater than water) enter a pipe with an average velocity of 4 ft as shown in Fig. P8.3. Would you expect the paint to exit the pipe as green paint or separate streams of blue and yellow paint? Explain. Repeat the problem if the paint were "thinned" so that it is only 10 times more viscous than water. Assume the density remains the same.

Key Concepts

Reynolds Number

The Reynolds number is a dimensionless parameter that indicates whether a fluid flow is laminar or turbulent by comparing inertial to viscous forces. It plays a crucial role in determining how different fluid streams interact. In highly viscous fluids, the Reynolds number is low, leading to laminar flow where streams maintain distinct pathways, whereas lower viscosity can lead to higher Reynolds numbers that promote turbulent mixing and intermingling.

Viscosity

Viscosity is a measure of a fluid’s resistance to gradually changing its shape when under stress. High viscosity dampens turbulence and minimizes shear instabilities, which limits mixing between adjacent streams. Conversely, lower viscosity allows for more inertially driven effects and enhances the possibility for turbulence and shear-induced mixing, increasing the likelihood that initially separate fluids will blend.

Laminar Flow

Laminar flow refers to a fluid motion where particles move in smooth, parallel layers without significant cross-currents or disruption between them. In this regime, mixing occurs only slowly through molecular diffusion rather than by turbulent eddies. This is important in flows with high viscosity, where even in confined geometries (like pipes) the streams can remain largely unmixed over short distances.

Diffusive Mixing

Diffusive mixing is the process by which two or more fluids mix due to the random motion (diffusion) of molecules. In a laminar flow, where advection dominates and turbulence is absent, the time scale for diffusion can be long compared to the residence time of the fluid within the system. Consequently, unless the molecular diffusion coefficient is high or the pipe is sufficiently long, initially separate streams may not fully mix by diffusion alone.
