Can a woman's height be predicted from her mother's height?...

Can a woman's height be predicted from her mother's height? The heights of some mother-daughter pairs are listed; $x$ is the mother's height and $y$ is the daughter's height.$$\begin{array}{l|llllllllll}\hline x & 63 & 63 & 67 & 65 & 61 & 63 & 61 & 64 & 62 & 63 \\y & 63 & 65 & 65 & 65 & 64 & 64 & 63 & 62 & 63 & 64 \\\hline\end{array}$$,$$\begin{array}{l|lllllllllll} \hline \boldsymbol{x} & 64 & 63 & 64 & 64 & 63 & 67 & 61 & 65 & 64 & 65 & 66 \\ \boldsymbol{y} & 64 & 64 & 65 & 65 & 62 & 66 & 62 & 63 & 66 & 66 & 65 \\\hline\end{array}$$. a. Draw two dotplots using the same scale and showing the two sets of data side by side. b. What can you conclude from seeing the two sets of heights as separate sets in part a? Explain. c. Draw a scatter diagram of these data as ordered pairs. d. What can you conclude from seeing the data presented as ordered pairs? Explain.

Can a woman's height be predicted from her mother's height? The heights of some mother-daughter pairs are listed; $x$ is the mother's height and $y$ is the daughter's height.$$\begin{array}{l|llllllllll}\hline x & 63 & 63 & 67 & 65 & 61 & 63 & 61 & 64 & 62 & 63 \\y & 63 & 65 & 65 & 65 & 64 & 64 & 63 & 62 & 63 & 64 \\\hline\end{array}$$,$$\begin{array}{l|lllllllllll}
\hline \boldsymbol{x} & 64 & 63 & 64 & 64 & 63 & 67 & 61 & 65 & 64 & 65 & 66 \\
\boldsymbol{y} & 64 & 64 & 65 & 65 & 62 & 66 & 62 & 63 & 66 & 66 & 65 \\\hline\end{array}$$.
a. Draw two dotplots using the same scale and showing the two sets of data side by side.
b. What can you conclude from seeing the two sets of heights as separate sets in part a? Explain.
c. Draw a scatter diagram of these data as ordered pairs.
d. What can you conclude from seeing the data presented as ordered pairs? Explain.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Association and Prediction

Visualizing paired data with a scatter diagram can reveal whether there is a linear or non-linear relationship between two variables, which is crucial for understanding whether one variable can be used to predict another. The strength and direction of the observed pattern give early insights into the potential for prediction through statistical models.

Visual Data Comparison

Using graphical methods such as dotplots and scatter diagrams provides an intuitive way to compare and understand different aspects of the data. When multiple sets of data are represented on the same scale, it facilitates direct comparison of their distributions and central tendencies.

Scatter Diagrams

A scatter diagram, or scatter plot, is used to display pairs of numerical data to determine if there exists a relationship or association between the two variables. Each point on the plot represents one observation for both variables, which helps in visualizing trends, patterns, correlations, or potential outliers.

Dotplots

A dotplot is a simple statistical chart that displays individual data points along a number line, allowing one to quickly see the distribution, frequency, and clustering of values. It is useful for comparing the shapes and spreads of two separate univariate data sets when plotted using the same scale.
