Can the voltage across a battery's terminals differ from the...

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Battery Rated Voltage

The rated voltage of a battery is the nominal value specified by the manufacturer based on its chemistry and design. It represents the ideal operating voltage when no load is applied, serving as a reference point for battery performance under standardized conditions.

Terminal Voltage

Terminal voltage is the actual voltage measuring at the battery's output when it is in use. This voltage can deviate from the rated voltage due to factors such as load conditions and internal battery characteristics.

Internal Resistance

Internal resistance is an inherent property of batteries that causes a voltage drop when current flows through the battery. This resistance affects the terminal voltage under load, making it lower than the rated voltage due to energy losses within the battery itself.

Load Effects

Load effects refer to the changes in battery voltage caused by the demand of the connected electrical load. When a load draws current from the battery, the voltage measured at the terminals can drop because of the voltage loss across the internal resistance, which may lead to a noticeable difference from the rated voltage.
