$\cdots$ A laser emits a cylindrical beam of light 3.4 $\mathrm{mm}$ in diameter. If
the average power of the laser is $2.5 \mathrm{mW},$ what is the rms value of
the electric field in the laser beam?

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Electromagnetic Intensity and the Poynting Vector

The intensity of an electromagnetic wave represents the time-averaged power per unit area, and it is described by the Poynting vector. In free space, the time?averaged intensity is given by I = (1/2) c ?? E_rms², which relates the rms (root mean square) value of the electric field to the energy flux carried by the wave.

Relationship Between Power, Intensity, and Beam Area

The total power emitted by a source distributed over an area can be converted into an intensity value by dividing the power by the beam's cross-sectional area. In the case of beams with a circular cross section, the area is calculated using A = ?(d/2)². This relationship is essential for determining the local energy density of the beam from its total power output.

RMS Electric Field Value

The root mean square (rms) value of the electric field provides a measure of the effective strength of a varying electromagnetic field in a wave. It represents the equivalent constant field that would deliver the same average energy flux as the oscillating field. The rms value is particularly useful for sinusoidally varying fields, linking the measurable intensity of the wave to the electric field amplitude.
