Collect information for a resistance- and thermocouple-based...

Collect information for a resistance- and thermocouple-based thermometer suitable for the range of temperatures from $0^{\circ} \mathrm{C}$ to $200^{\circ} \mathrm{C}$. For each of the two types, list the accuracy and response of the transducer (output per degree change). Is any calibration or correction necessary when it is used in an instrument?

Key Concepts

Calibration and Correction

Both resistance-based sensors and thermocouples typically require calibration to translate the raw output into accurate temperature readings. Calibration involves comparing sensor outputs to a known temperature standard and applying correction factors to account for nonlinearity, drift, or other errors. This step ensures that the instrument provides reliable and repeatable temperature measurements across its designated operating range.

Transducer Sensitivity and Response

Sensitivity in temperature transducers is defined as the change in sensor output (e.g., voltage or resistance) per degree change in temperature. This characteristic is crucial because it determines the sensor's ability to resolve small temperature variations. For resistance thermometers and thermocouples, the sensitivity—or transducer response—directly impacts the resolution and precision of the temperature measurement, driving design choices in instrumentation.

Thermocouple

A thermocouple is a temperature sensor that exploits the Seebeck effect, where a voltage is generated at the junction of two dissimilar metals when there is a temperature difference. The output voltage is typically in the millivolt range per degree change in temperature, which means its sensitivity is defined by the produced voltage per unit temperature difference. Thermocouples are valued for their wide operating range and fast response times, even though their accuracy is generally lower than that of resistance-based sensors.

Resistance Thermometer

A resistance thermometer measures temperature by exploiting the predictable change in electrical resistance that occurs in certain materials (often metals like platinum) as temperature varies. The device converts these resistance changes into temperature readings with specified accuracy and sensitivity, meaning that a consistent change in resistance corresponds to each degree change in temperature. These sensors are prized for their high accuracy over moderate temperature ranges and are common in both industrial and laboratory applications.
