00:01
For this problem, we're going to be considering benzene and vapor pressure.
00:05
And we've got three things we're going to figure out.
00:08
First is the normal boiling point.
00:17
And second is we're going to plot the data.
00:22
More to follow on this.
00:25
And when we plot the data, we're going to have to figure out the temperature at 250 mmhg.
00:45
And the temperature at 650 millimeters of mercury after we plot the data.
00:56
And then for c, we're going to calculate the molar enthalpy of vaporization.
01:11
So those are the things that we're going to do in this problem.
01:16
So the data.
01:17
Data are going to be a little strange because i'm under some issues where i can't give you the data table.
01:28
So i'm going to try to do this without giving you the data table.
01:30
Table i'm just going to mark my graph 100 whoops trying to get these right on the line 100 200 300 400 400 600 700 if i need more i'll put those in there and this is our vapor pressure i'm going to write my label down here vapor pressure in millimeters mercury and my temperature is down here and i need to go up to about i'm going to go 10, 20, 30, 40, 50, 60, 70, 80, 90.
02:23
And this is temp in c degrees.
02:36
Okay, so my first data set will be, for my x axis, will be 7 .6 degrees c and 40 mmhg.
02:50
So i'm going to go to 7 .6, which is right about here and 40, which is right about there.
02:57
So there's my first data point.
02:59
I'll mark my data with an x.
03:01
My second data point will be 26 .1 degrees c and 100 millimeters mercury.
03:11
So there's 100 and there's 26, right about there.
03:18
I'm a little high on that one.
03:21
Right about there.
03:24
And my third point will be 60 .6 degrees c and 400 mmhg.
03:36
So i'm at 400, which is right there, and 60, which is right about there.
03:45
And my last data point is 80 .1 degrees c and 760, one atmosphere hg.
03:55
So i'm at just about exactly 80 and 760.
03:59
Is right about here.
04:02
So there's my data points.
04:04
Okay, so let's go ahead and i'm going to do a light color.
04:09
So this is going to, this is not going to be a pretty graph.
04:16
I'm already not doing well, but there, that's good enough.
04:21
I think you get the general idea...
