Compute the number of bits required to store an uncompressed image. (a) Suppose one wanted to have 128 shades of gray (ranging from pure white to pure black) in the image, how many bits per pixel would be required to specify the gray level or brightness? (b) Consider a color image of $640 \times 480$ pixels (standard VGA resolution), in which each pixel has separate red, green, and blue levels of brightness. How many bits are required to store this image with no compression? Compare this with the size of a typical VGA jpeg image stored on your $\mathrm{PC}$. (Don't forget that on a $\mathrm{PC}$, file sizes are given in bytes and 1 byte $=8$ bits.)

Key Concepts

Bytes and Bits Conversion

File sizes and digital storage capacities are typically measured in bytes, while the number of bits is used in computation. Since 1 byte equals 8 bits, converting between these units is essential when comparing the size of digital files and understanding storage requirements.

Image Compression

Image compression refers to reducing the amount of data required to represent an image, often by eliminating redundant information. While uncompressed images store every bit of pixel data, compressed images (such as JPEGs) use algorithms to reduce file size, resulting in much smaller file sizes compared to their uncompressed counterparts.

Image Resolution

Image resolution, defined as the number of pixels along the width and height of the image, is crucial in determining the total amount of data required to store an image. Higher resolution images contain more pixels and therefore require more storage, even if each pixel uses the same number of bits.

Binary Representation

This concept involves representing information (such as color or brightness values) using bits, where each bit has two states (0 and 1). Understanding binary representation is fundamental to determining how many bits are needed to encode a specific number of states, as the number of different possible states is given by 2 raised to the number of bits.

Grayscale Image Bit Computation

For grayscale images, the total number of gray levels determines the number of bits needed per pixel. This involves identifying the smallest power of two that is at least as large as the number of gray levels required. For example, if an image needs a certain number of distinct shades, one must calculate the logarithm base 2 of that number and round up to determine the minimum number of bits per pixel.

Color Image Storage

Color images are typically composed of multiple channels (commonly red, green, and blue), each of which is stored separately with a fixed number of bits. The overall storage for an image is calculated by multiplying the number of pixels by the total number of bits per pixel, which is derived from the sum of bits for each individual color channel.
